Microsorber - ETFE UV Protected Acoustic Film
Verified by manufacturer 2 months ago
Transparent Microsorber
Transparent Microsorber
An innovative sound comfort optimizer reducing sound reflection due to the use of a micro-perforated foil.
Application
Whether in open-plan offices, canteens, swimming pools, production sites or entrance halls – the MICROSORBER® principle of transparent sound absorption allows for creativity in the design of buildings where room acoustics play a crucial role.
Description
An innovative sound comfort optimizer reducing sound reflection thanks to the use of a micro perforated foil. As soon as sound waves strike the microperforated surface, a physical reaction takes place: sound energy is converted into energy through the friction arising at the hole edges.
The product can be installed in front of walls and glass façades and below ceilings. Various systems for fastening the foil make it possible to attach and detach individual elements with ease. MICROSORBER® membranes are printable. They combine acoustic absorption, translucence and design. The membranes are UV stabilized and can be installed on glass facades guaranteeing the image will not deteriorate. Fie rated B-S1, d0 (DIN EN 13501-1) and A+ indoor air quality rating.
General information
Color | White Clear Beige Black Blue |
Finish | Film |
Material | Fluoropolymer resin Manufacturer guidanceEFTE/Film. |
Shape | Square Rectangle |
Length | Bespoke |
Width | 1550 mm |
Height | Bespoke |
Warranty description | Ten year |
Uniclass | |
CAWS | H90/140 Internal single layer fabric system |
Specification data - Fabric membrane ceiling systems
Ceiling support | 52 mm Stainless Steel Spacer.90 mm Stainless Steel Spacer.140 mm Stainless Steel Spacer. |
Support fasteners | 0° Tensioning Spring.180° Tensioning Spring.270° Tensioning Spring.270° Angle 80° Tensioning Spring.180° Angle 80° Tensioning Spring. |
Ceiling fabric | Stretch fabric membranes (ETFE foil). |
Samples required | Samples available on request. |
Sustainability data
Contains Red List materials | No |
Country of material origin | France |
Country of product manufacture | France |
Material | Fluoropolymer resin Manufacturer guidanceEFTE/Film. |
Recyclability | 100% |
Expected Life | 30 year |
Literature
Barrisol Microsober
Microsorber by Barrisol
