Mirox 4Green+

Verified by manufacturer 6 months ago

AGC Glass UK Ltd

Premium mirrors using lead-free, water-based paint, particularly suited to backlit applications.

Jump to:
+44 (0)1788 535353 Website

Application

Indoors only for use as a mirror, including:

  • Furniture: partitions, tables, shelves, fixed and sliding doors for cupboards and wardrobes, display cases and glass boxes, etc;
  • Wall cladding: Bathrooms, shopping malls, restaurants, schools, hotels, elevators areas, etc;
  • Doors: sliding doors for furniture.

Description

Premium mirrors using lead-free paints.


Features and benefits:

  • Fully opaque paint offers superior opacity, a key feature when the mirror is backlit using LED strips.
  • The patented manufacturing process ensures that Mirox 4Green+ is a high quality, highly resistant mirror that easily exceeds the most stringent quality and resistance standards.
  • Available in a MIROX SAFE+ safety version.
  • Close to zero indoor emissions of volatile organic compounds (A+*, per French Decree No. 2011-321), including very low levels of formaldehyde.
  • Good quality of air inside the building maintained.
  • Special double-layer paint provides excellent anti-corrosion protection for the silver layer outperforming EN 1036.
  • No lead intentionally added: Contains only limited lead contamination (0.004%) from other natural materials used for the production of the paint. Compliant with RoHS Directive 2011/65/EU.
  • Compatible with AGC's FIX-IN bonding solutions.
  • Easy to process.


For a high-quality alternative, see Mirox MNGE, or for an antique appearance, see Mirold Morena (both specified separately).

General information

Color

Bronze

Clear

Grey

Other

Guidance for specification option:

Clearvision.

Material

Glass

Uniclass

Pr_40_30_53_30 Framed glass mirrorsPrimary

CAWS

L40/91 Glass mirrors

L40/550 Glass mirrors

N10/270 Mirrors

N10/75 Framed mirrors

Specification data - Framed glass mirrors

Standards

To BS EN 1036-2.

Materials and standards

-

Safety requirements

Manufacturer's standard.

SAFE+.

Guidance for specification option:

For extra safety a film can be applied to the painted side of the Mirox mirror. The film has two purposes:

  1. If the glass breaks, the shards will stick to the film, preventing injury and any further damage;
  2. It protects the painted surface of the glass from scratches.

Materials

Float glass.

Dimensions

-

Manufacturer guidance

Insert requirements: from 2000 x 3210 mm to 6000 x 3210 mm.

Thickness

3 mm.

4 mm.

5 mm.

6 mm.

Finish

Manufacturer's standard.

Backing

Double layer anticorrosive paint.

Edges

-

Treatment

Manufacturer's standard.

Ground.

Profile

Manufacturer's standard.

Other.

Guidance for specification option:

Insert requirements.

Provision for fixing

FIX-IN AT.

Guidance for specification option:

Specified separately.

FIX-IN PR.

Guidance for specification option:

Specified separately.

FIX-IN SA.

Guidance for specification option:

Specified separately.

FIX-IN SL.

Guidance for specification option:

Specified separately.

Other.

Manufacturer guidance

AGC Fix-In products are recommended for installation.

Accessories

-

Manufacturer guidance

Consult manufacturer for further details and insert requirements.

Colour

Mirox 4Green+ Clear.

Guidance for specification option:

Normal float base.

Mirox 4Green+ Clearvision.

Guidance for specification option:

Highly neutral float base for pure aesthetics.

Mirox 4Green+ Bronze.

Mirox 4Green+ Grey.

Third-party certification

Cradle to Cradle Certified™ Bronze.

Processing

Not required.

Cutting, straight.

Guidance for specification option:

Insert requirements.

Cutting, circular.

Guidance for specification option:

Insert requirements.

Grinding.

Guidance for specification option:

Insert requirements.

Bending.

Guidance for specification option:

Insert requirements.

Show more

Manufacturer guidance

Consult manufacturer for further details.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe
