Mirror Acoustic
Barrisol Mirror & Stainless Steel membranes mounted on self-supporting frame, it can be luminous, printed, acoustic, organically shaped and 3D. Fire rated to comply with international standards.
All buildings for private and public sectors including hospitality, residential, commercial, where you wish to have a unique design. Covering the entire ceiling or as independent frames of all shapes.
Specially designed to be mounted on frames of any shape (2D or 3D), these membranes will add an exceptional touch to any décor. Remarkably, Barrisol Mirror® combines the reflective power of a mirror and the technical characteristics of stretched Barrisol® membranes to create a perfect illusion and “extend” your interior, giving the impression of space.
Stainless Steel has the same characteristics as the above but with a similar look as stainless steel.
Whether printed or back-lit, Barrisol Mirror® & Stainless Steel membrane use an exclusive micro-perforation system to enhance the acoustic comfort in any space.
The Barrisol Mirror® & Stainless Steel membrane, in addition to its many aesthetic characteristics, is available in an acoustic version. It combines reflective power and acoustic comfort thanks to an exclusive Barrisol® system of micro-perforations.
Features and benefits:
Color | Black Copper Gold Silver Guidance for specification option: Silver stainless steel. Bronze |
Finish | Smooth Antiqued Guidance for specification option: Antique stainless steel. Mirrored Brass Brushed |
Material | Vinyl Guidance for specification option: Vinyl with film. |
Shape | Other Guidance for specification option: Bespoke. Circle Oval Triangle Square |
Length | Bespoke |
Width | Bespoke Manufacturer guidanceAlso customisable. |
Height | 37 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | H90/140 Internal single layer fabric system |
Ceiling support | BMR 385/05.Guidance for specification option: Aluminium profile for modular frame BMR 385/06.Guidance for specification option: Aluminium profile BMR 385/07.Guidance for specification option: Aluminium profile BMR 385/08 LED.Guidance for specification option: LED separator for mirror BMS 365/80.Guidance for specification option: Cover, not bendable B440/62.Guidance for specification option: Clip PVC BMR 385/01.Guidance for specification option: Aluminium profile for modular frame BMR 385/02.Guidance for specification option: Aluminium profile for modular frame BMR 385/03.Guidance for specification option: Aluminium profile BMR 385/04.Guidance for specification option: Aluminium profile Manufacturer guidanceConsult technical literature for details and insert requirements. |
Ceiling fabric | NANOPERF.Guidance for specification option: A15 - Ø0.1mm ACOPERF.Guidance for specification option: A20 - Ø0.15mm MICROACOUSTIC.Guidance for specification option: A30 - Ø0.2mm MINIPERF.Guidance for specification option: A40 - Ø0.5mm Manufacturer guidanceConsult literature for details. |
Colour | Black. Gold. Silver. White. Tin moiré. |
Contains Red List materials | No |
Country of material origin | France |
Country of product manufacture | France |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 70 % |
Platform | Compatible | Version |
---|---|---|
- | 1 |
