Moralt Ferro Passiv 98 mm - Door blank

Verified by manufacturer 5 months ago

James Latham

Passive house-certified timber external door blank.

Jump to:
+44 (0) 207 288 6417 Website

Application

Suitable for external doors.

Description

98 mm thick PEFC® certified timber external door blank with Passive house certification for low-energy and Passive houses. Its technically sophisticated construction provides optimum conditions for a comfortable indoor climate and includes a lock-side, patented, flat steel stabilizer, thermally separated and sound insulated to absorb tractive and shearing forces.


Features and benefits:

  • Certified single/ double leaf with and without vision panels.
  • Lightweight, yet strong and stable.
  • Cut-to-size panels.
  • Excellent stability and durability ratings.
  • WK2/ WK3 burglar resistance.
  • PAS 24 certified.
  • Passive house-certified.
  • Sandwich construction of laminated core (spruce) and HCFC-free and environmentally compatible PU hard foam with vertically aligned annual rings.

General information

Material

Wood

Shape

Rectangle

Length

-

Manufacturer guidance

As drawing/ schedule, insert reference.

Uniclass

Pr_30_59_23_97 Wood flush door leavesPrimary

CAWS

L20/20 Wood flush doors

L20/230 Wood flush doors

Product range

Door Blanks

Specification data - Wood flush door leaves

Thickness

98 mm.

Door leaf size

2470 x 1150 mm.

Guidance for specification option:

Maximum size.

AcousticRating

31 dB.

Guidance for specification option:

Standard.

43 dB.

FireRating

None.

Guidance for specification option:

Standard.

FD30.

Materials

Guidance for specification option:

Sandwich construction of laminated core (spruce) and HCFC-free and environmentally compatible PU hard foam with vertically aligned annual rings.

Weight

35 kg/m².

U-value

0.54 W/m²K.

Literature

Doors - Moralt Door Blanks

Doors - Moralt Door Blanks

Doors - Moralt Ferro 68-98mm Test Reports PAS 24 / BS 6375 - 1 of 3

Doors - Moralt Ferro 68-98mm Test Reports PAS 24 / BS 6375 - 1 of 3

Doors - Moralt Ferro 68-98mm Test Reports PAS 24 / BS 6375 - 2 of 3

Doors - Moralt Ferro 68-98mm Test Reports PAS 24 / BS 6375 - 2 of 3

Doors - Moralt Ferro 68-98mm Test Reports PAS 24 / BS 6375 - 3 of 3

Doors - Moralt Ferro 68-98mm Test Reports PAS 24 / BS 6375 - 3 of 3

Doors - Moralt Ferro Passiv Flyer

Doors - Moralt Ferro Passiv Flyer
