MuteMat® Acoustic Flooring Systems - Floor Soundproofing System

Verified by manufacturer 16 days ago

MuteMat® + - Gold

iKoustic Variant:

Acoustic flooring for commercial and residential environments.

Jump to:
+44 (01937) 588 226 Website

Application

  • Suitable for homes, workplaces, and public buildings where noise needs to be reduced between floors.
  • For timber or concrete floors in both new builds and refurbishment projects.

Description

iKoustic Flooring Systems provide a high-performance solution for soundproofing floors in residential, commercial, and specialist environments. Each system is designed with a focus on acoustic integrity, ease of installation, and long-term durability.

Features and benefits:

  • Reduces both airborne and impact sound transmission between floor levels.
  • Designed to integrate with a variety of floor constructions including timber joist, concrete slab, and floating floors.
  • Compatible with underfloor heating systems (select systems).
  • Combines high-mass and vibration-isolating materials for optimal acoustic performance.
  • Offers a range of solutions including:
    • MuteMat® 2 and MuteMat® 3: High-density rubber composite mats designed to isolate impact and airborne noise.
    • MuteMat® OSF: Over-screed floating system for robust performance in high-traffic or demanding environments.
  • Suitable for new builds, refurbishments, and listed building applications.
  • Lightweight and easy to handle, with minimal construction height increase across most products.
  • Products made from recycled materials where possible, contributing to sustainable building practices.

General information

Color

Black

Blue

Beige

Brown

Finish

Smooth

Material

Vinyl

Guidance for specification option:

Mass loaded vinyl (MLV).

Foam

Guidance for specification option:

Closed cell foam.

Mineral wool

Shape

Square

Length

Bespoke

Width

Bespoke

Height

10 mm

17 mm

21 mm

Uniclass

Ss_25_25_75_05 Acoustic panel lining systemsPrimary

CAWS

K11/275 Acoustic separating floor system

K11/27 Acoustic separating floor system

Specification data - Acoustic panel lining systems

Classification data

System performance

Acoustic performance

Acoustic insulation

Mineral wool slab insulation.

Panelling

-

Type

1 x MuteMat® 3 with Tecsound®.

Guidance for specification option:

  • MuteMat® 3: 12 mm acoustic underlay that can be laid on top of timber or concrete floors to reduce impact and airborne noise. Carpet, wood, tile and vinyl flooring can be laid on top.
  • Tecsound®: A flexible, easy to handle and high performing acoustic membrane for soundproofing.

Surface material

Vinyl.

Surface finish

-

Manufacturer guidance

Consult manufacturer and insert requirements or omit.

Fasteners

-

Manufacturer guidance

Consult manufacturer and insert requirements.

System accessories

-

Manufacturer guidance

Consult manufacturer and insert requirements or omit.

Isolator

Isolation Strip P8.

Guidance for specification option:

A strip of self-adhesive pimpled rubber used for reducing impact sounds travelling from the floor to rooms below. The P8 isolation strip is applied to the floor joists.

Depth

21 mm.

Overall size

-

Manufacturer guidance

Consult manufacturer and insert requirements.

Noise reduction coefficient

22 dB.

Sustainability data

Material

Vinyl

Guidance for specification option:

Mass loaded vinyl (MLV).

Foam

Guidance for specification option:

Closed cell foam.

Mineral wool
