myRENZbox Modula Extension Module - Intelligent Smart Parcel Boxes

Verified by manufacturer 4 months ago

Module A

The Safety Letterbox Company Variant:
Third party certifications:
  • Secured By Design

    Secured By Design

    Certificate type

A fully scalable intelligent parcel box system.

Jump to:
+44 (0)1639 633525 Website

Application

For internal and external applications.

Description

A fully scalable intelligent parcel box system with proven functionality. The combination of hardware and unique RENZ software platform enables full automation of the parcel delivery, collection and returns process.


Part of the Classic range, MODULA is a fully scalable intelligent parcel box system with proven functionality at the best price. The combination of hardware and unique RENZ software platform enables full automation of the parcel delivery, collection and returns process.


At the ‘heart’ of this scalable system is a choice of two standalone control modules with the option of a further nine parcel extension modules. The system can be extended to manage up to 500 box compartments with electronic locks operated from a single controller.


Extension modules are simply added to the control module to match the exact project requirements. We provide guidance to help configure the specific number and size distribution of parcel boxes required for each project.


Features and benefits:

  • No access for general public.
  • Easy to use system from management through to residents.
  • Dynamically allocated units.
  • Controlled via our portal for full access and reportability.
  • Tried and tested in the marketplace.
  • QDPR compliant – no residents details visible.
  • Offers you and the management team onsite minimal involvement from the management team, after initial setup.
  • Carriers deliver direct.
  • Residents collect direct.
  • 8” control screen.
  • Barcode scanner.
  • Online portal.
  • Management tags.
  • Bluetooth.
  • Other finishes available, stainless steel, coated.
  • Anti-microbial protection.
  • IASME Level II Certified

General information

Color

Beige

Black

Blue

Brown

Cream

Show more

Manufacturer guidance

Any RAL colour from the standard colour range, contact manufacturer for details.

Finish

Powder-coated

Material

Steel

Shape

Rectangle

Length

408 mm

Width

300 mm

Height

1828 mm

Warranty description

Two year

Uniclass

Pr_40_30_50_46 Letter boxesPrimary
Pr_40_30_87_48 Lockers

CAWS

N10/400 Mailboxes

N10/96 Mailboxes

Specification data - Letter boxes

Standard

To BS EN 13724, EN ISO 12100:2010, EN 60204-1:2006, CE certified.

Classification grades (minimum)

-

Type of aperture

Full door smart.

Aperture size

Full door parcel box.

Security

IASME Level 2 - IOT Cyber Assurance.

Fire resistance

Class 0.

Size

408 x 1828 x 533 mm.

Guidance for specification option:

Depth x Height x Width.

Materials

Steel.

Colour and finish

Polyester powder-coated, RAL.

Manufacturer guidance

Powder-coated to any RAL, including vinyl wraps and Cotech protective coating. Please insert requirements.

Integral accessories

None.

Vinyl wrap.

Tech pack.

Image pack.

Fire rated option.

Cotech protective coating.

Net weight

113 kg.

Weight

323 kg.

Power consumption

43.8 kw.

Guidance for specification option:

Yearly.

Configuration

4 x small parcel boxes; 1 x small parcel box; 3 x medium parcel boxes.

Manufacturer guidance

The configuration is calculated using the Safety Letterbox Company's algorithm to each individual site requirement. Flexible and future-proofed.

Sustainability data

Contains Red List materials

No

Country of material origin

Germany

Country of product manufacture

Germany

Material

Steel

Recyclability

100%

Third party certifications

Secured By Design

Secured By Design

IASME IOT Cyber Assurance Level 2
