Pre-cast Concrete Treads
Verified by manufacturer 2 months ago
Handmade pre-cast concrete treads for internal and external use. Variety of different styles available including flat treads, treads & risers, L shaped treads & hollow sleeves to encase a bracket.
Application
Bespoke moulds are created which concrete is then poured into and finished. The treads are then shipped to site where they are laid over a supporting structure as a capping system. Contrasting colour nosings can be incorporated into the tread.
Description
Handmade pre-cast concrete treads for internal & external use.
Features and benefits:
- Available with a polished or textured, anti-slip face.
- 40mm thickness
- Can be bedded with a simple adhesive
- Pre-sealed with a penetrative sealer.
- Includes cast in lifting socket to BS 5080.
- Available in 15 standard colours as well as the option to create bespoke colours.
- Provides a complimentary finish to a polished concrete floor allowing a continuation through a staircase.
- All sizes are created bespoke to perfectly fit each design
- Nosing strips can be embedded into the treads
- Landing/half landing slabs can also be created
- Typically laid over a rigid sub base such as steel or concrete
- Water based low VOC sealant is used
General information
Color | Grey Brown Purple Black Green |
Finish | Smooth Guidance for specification option: Polished. Textured Guidance for specification option: Anti-slip. |
Material | Concrete Guidance for specification option: C28/35 to C50 self-compacting concrete to BS EN 206-1 and BS 8500-2 |
Shape | Rectangle Kite Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | L30/20 Stairs L30/270 Stairs L30/30 Proprietary stairs L30/310 Proprietary stairs |
Specification data - Concrete step units
Dimensions | |
Thickness (minimum) | 40 mm. |
Colour | August grey.Azure grey.Chestnut.Coast.Dusk.Ebony.Forest.Fossil.Marble.Midnight.Platinum grey.Sahara.Silver sleet.Tempest.Special order.Guidance for specification option: Insert RAL colour requirement. |
Reinforcement | High bond bars. Guidance for specification option: Standard. Special order. Guidance for specification option: Insert requirement, contact manufacturer for information. |
Sealer | Not required. Gloss. Matt. Satin. |
Materials | C28/35 to C50 self-compacting concrete to BS EN 206-1 and BS 8500-2. |
Pendulum test value | >36. Manufacturer guidance(Wet pendulum test). |
Edges | Square. |
Surface finish | Smooth. Guidance for specification option: Polished. Textured. Guidance for specification option: Anti-slip. |
Sizes | Guidance for specification option: Insert reference, available up to 1200 x 1200 mm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Concrete Guidance for specification option: C28/35 to C50 self-compacting concrete to BS EN 206-1 and BS 8500-2 |
Manufacturing plant location |
Case studies
Hawley Wharf
