Premier E Doorset - Single External Entrance Doors
Verified by manufacturer 4 months ago
Secured By Design
Certificate type
An outward opening polyester powder coated fully galvanized steel door set manufactured from hollow steel profiles and sheet material, in a combination of welds and bolted construction. mag locks
Application
Suitable applications include:
- Council buildings.
- Entrance doors.
- Security doors.
- Sheet metal doors.
- Access control doors.
- Flat entrance doors.
- Communal door set.
- Door entry compatible.
- Housing.
- Student accommodation.
- Residential.
- Refurbishment.
- New build.
Description
The Premier Security Door includes patented technology and meets the requirements of STS 202 Level 2 (PAS23/24) and has also achieved accreditation from Secured By Design.
When no Secured by Design Certification is required, the door can be designed to suit many glazing configurations.
Features and benefits:
- Can integrate with any electrical door entry system.
- Strong welded construction to withstand high impact.
- Low maintenance costs.
- Quick and easy to repair when needed.
- Tamper proof locking and wiring.
- Proven durability.
- DDA-compliant threshold.
- Patented anti-nip hinge.
- Galvanized and powder coated to resist corrosion.
- Inner and outer skins are thermally broken.
- Available in standard RAL polyester powder coating.
- Concealed transom closer.
- Comprehensive range of styles.
- Factory fitted mag lock.
General information
Color | Blue Green Orange White Yellow |
Material | Steel |
Shape | Rectangle Square |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year Guidance for specification option: There is also the option of an extended warranty consult manufacturer for further information. |
Uniclass | |
CAWS | L20/60 Doors L20/280 Doors L20/55 Doorsets L20/480 Doorsets |
Specification data - Carbon steel doorsets
Configuration | Single-leaf, single-action. |
Doorset size | Guidance for specification option: Bespoke consult manufacturer and insert requirements. |
Performance | |
Intruder resistance | |
Minimum requirement | Secured by Design certification. To STS202, BR 2. |
Application | Both sides. |
Conformity | Certification by accredited third-party certification body. Type testing not permitted. |
Frame | |
Material | Carbon steel. |
Threshold | Low level aluminium threshold. |
Perimeter seals or inserts | Silicon sealant. |
Finish | |
Coating | Polyester powder-coated. |
Texture | Smooth.Textured. |
Colour | Guidance for specification option: Powder coated to any RAL Classic colour. Consult manufacturer and insert requirements. |
Installation fasteners | Guidance for specification option: Consult manufacturer and insert requirements. Doorsets to be fixed into position using appropriate length, fit for purpose straps or through frame fixings. |
Frame accessories | Anti-nip hinge.Full length piano hinge.Guidance for specification option: Where required (not SBD tested). |
Door leaf | |
Panel details | Galvanized steel doorset manufactured from hollow steel profiles and sheet material. |
Material | Carbon steel. |
Perimeter seals | Silicon sealant. |
Glazing | |
Type | 8 mm polycarbonate.Guidance for specification option: Tested to SBD STS 202 level 2. 6.4 mm laminate glass.Guidance for specification option: If SBD STS 202 level 2 not required. Manufacturer guidanceDouble glazed units manufactured to BS EN 1279:2002. BS EN 12600: 2002 Glass in building – Pendulum test – Impact test method and classification for flat glass. |
Beading | |
Material | Steel.Guidance for specification option: 20 mm. Powder coated to any RAL Classic colour. Consult manufacturer and insert requirements. |
Finish | |
Coating | Polyester powder-coated. |
Texture | Smooth.Textured. |
External colour | Guidance for specification option: Powder coated to any RAL Classic colour. Consult manufacturer and insert requirements. |
Internal colour | Guidance for specification option: Powder coated to any RAL Classic colour. Consult manufacturer and insert requirements. |
Film thickness (minimum) | 80–120 micrometres. |
Door accessories | Stainless steel D ring handle to the outside and SS push-plate to the inside. |
Accessories | Not required.Additional magnetic lock.Guidance for specification option: Where requested an additional Magnetic lock of 245 kg can be added. Rear door lever and latch.Guidance for specification option: Rear doors to have lever handle and latch to inside and keyed opening only to outside (not SBD tested). |
Ironmongery | Magnetic lock. Guidance for specification option: One Mag Lock of 545 kg, fully rebated into door frame. |
Closers | Concealed access red transom closers. Briton closer. Guidance for specification option: Where required (not SBD tested). Concealed Dorma T96 closer. Guidance for specification option: Where required (not SBD tested). |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Steel |
Manufacturing plant location | |
Recyclability | The product is manufactured from all Steel RHS sections with nuts and bolts giving the product the ability to be fully recyclable. Only disposal parts on the system are glazing gaskets and glass. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 75 % |
Expected Life | 20 year |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
Secured By Design
Certificate Number CS5003
Literature
Premier E Doorset
Door Case Study
Premier E Door Set STS 202 BR 2 Certificate
