Prevista Pure Concealed Cistern (floor standing WC)
Verified by manufacturer 18 days ago
Model 8502.38
Model 8502.38
KIWA BDA
Certificate type
Concealed cisterns for floor standing WCs.
Application
Suitable for use with floor standing WCs.
Description
A variety of concealed cisterns for use with WCs suites.
Concealed cistern 3H (long flushing pipe elbow)
■ for floor-standing WC, immurement and encircling wall
■ compatible with all WC flush plates for Prevista, flush actuation from front, dual flush technology
■ WRAS / KIWA approved
Article Number: 804 657
Concealed cistern 3L (short flushing pipe elbow)
■ for floor-standing WC, immurement and encircling wall
■ compatible with all WC flush plates for Prevista, flush actuation from front or top, dual flush technology
■ WRAS / KIWA approved
Article Number: 804 664
Features and benefits:
- Compatible with all WC flush plates for Prevista.
- Flush actuation from front or top.
- Dual flush technology.
General information
Color | White |
Shape | Rectangle |
Length | Bespoke |
Width | 416 mm |
Height | Bespoke |
Warranty description | Six year |
Uniclass | |
CAWS | N13/10 WC pans and flushing arrangements N13/300 WCs and cisterns |
Product range |
Specification data - WC cisterns
Approval | Water Regulations Advisory Scheme (WRAS)-approved. |
Form | Concealed. |
Materials | |
Body | Plastics. |
Finish and colour | White. |
Capacity | 6/3 L dual flush.Guidance for specification option: Partial flush volume factory setting approx. 3 L. Partial flush volume setting range approx. 2–4 L. Full flush volume factory setting approx. 6 L. Large flush volume setting range approx. 3.5–7.5 L. |
Water supply, overflow and outlet holes | |
Water supply | Back and top inlet. |
Integral accessories | Filling valve type AG (tested to BS 1212‑4:2016 in accordance with WRAS certification number 2103302), flushing throttle, WC connection fitting, fixing material, alignment help, water connection R½ at the back and top. |
Options | Concealed cistern 3H. |
Height | 1077 mm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
Third party certifications
Literature
Viega Prevista Brochure
