Profile 21 Rimmed Back Inlet Urinal Bowl - Urinal
Verified by manufacturer today
EPD
Certificate type
Urinal bowl with flushing provided from mains feed.
Application
Suitable for the following sectors:
- Education.
- Offices.
- Sports and leisure.
Description
Rim urinal with flushing provided from mains feed. Not suitable for flushing from a cistern.
Features and benefits:
- Fully concealed.
- Sensor flush.
- Easy clean design.
- Flushed from mains water.
General information
Color | White |
Finish | Gloss |
Material | Vitreous china |
Shape | Other |
Length | 335 mm |
Width | 325 mm |
Height | 570 mm |
Warranty description | Lifetime |
Uniclass | |
CAWS | N13/315 Urinals and auto-flushing cisterns N13/15 Urinals and cisterns |
SKU Code | E570101 |
GTIN/EAN | 5017830480587 |
Specification data - Wall-hung urinals
Classification data | |
Standards | To BS EN 13407. |
Class | 2. |
Form | Bowl. |
Materials | |
Body | Vitreous china. |
Finish and colour | White. Guidance for specification option: 01 - white glossy. |
Water supply, overflow and waste holes | |
Water supply | Back inlet. |
Width | 325 mm. |
Height | 570 mm. |
Projection | 335 mm. |
Net weight | 15.00 kg. |
Sustainability data
Material | Vitreous china |
Product certifications
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Product certifications
EPD
EPD - Ceramic Vitreous China
Literature
Literature type
Profile 21 Rimmed Back Inlet Urinal Bowl - Data Sheet
Commercial RMI
