Application

Suitable in residential and light commercial applications, including:

  • Housing.
  • Retail units.
  • Offices.

Description

RD70 TruEnergy Doors are engineered to deliver impressive performance levels and fully suite with the TruEnergy SW60 residential and TW70 commercial window ranges.

This versatile residential/ light commercial door system can be used as a front entrance door, side entrance door and rear entrance door and is available in both single and double door combinations. All of this is in a flush finish. It is a particularly suitable solution for any new-build residential project, as well as being perfect for home renovations and refurbishments.

Features and benefits:

  • Single and double doors.
  • Open in and open out.
  • Flush finish.
  • Internally glazed.
  • Manual and auto-engage multi-point locking options
  • Adjustable hinges.
  • Fully mitred.
  • Choice of thresholds: standard and low.
  • Available in standard and non-standard colours, and is also available in dual-colour combinations.
  • PAS 24 security.
  • Secured by Design.
  • Suites with TW70 and SW60 TruEnergy window systems.
  • Document L compliant.

General information

Color

Beige

Black

Blue

Bronze

Brown

Show more

Finish

Powder-coated

Material

Aluminium

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Other

Uniclass

Pr_30_59_24_02 Aluminium doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

SKU Code

RD70

Specification data - Aluminium doorsets

Classification data

Standard

External non-fire-rated aluminium alloy doorset.

Configuration

Single-leaf, single-action (open in).
Single-leaf, single-action (open out).
Double-leaf, single-action (open in).
Double-leaf, single-action (open out).

Doorset size

-

Manufacturer guidance

Insert requirements.

  • Single door maximum width: 1100 mm (frame).
  • Single door maximum height: 2500 mm (frame).
  • Double door maximum width: 1800 mm (frame).
  • Double door maximum height: 2500 mm (frame).

Performance

-

Acoustic performance

Unrated.

Strength and durability

Unrated.

Thermal

-

Manufacturer guidance

U-Value of 1.3 W/m²K (0.7 centre pane value with infills).

U value of 1.5 W/m²K (1.0 centre pane value with infills).

Consult manufacturer for details and insert requirements.

Intruder resistance

-

Minimum requirement

To PAS 24.
Secured by Design certification.

Conformity

Certification by accredited third-party certification body. Type testing not permitted.

Frame

-

Material

Aluminium.

Threshold

Standard threshold.
Low threshold.

Perimeter seals or inserts

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Finish

-

Coating

Polyester powder-coated.

Texture

Gloss.
Matt.
Satin.
Textured.

Colour

-

Manufacturer guidance

Insert requirements.

  • Available in standard and non-standard RAL colours.
  • Powder coat as standard provided by Qualicoat approved supplier.
  • Consult manufacturer for details.

Installation fasteners

-

Manufacturer guidance

Consult manufacturer for details and insert requirements.

Frame accessories

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Door leaf

-

Thickness

70 mm.

Core

Manufacturer's standard.

Panel details

Manufacturer's standard.

Material

Aluminium.

Perimeter seals

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Glazing

-

Type

Glazed, 28 mm.
Glazed, 36 mm.
Glazed, 44 mm.

Manufacturer guidance

Internally glazed.

Consult manufacturer for details.

Manifestation

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Glazing accessories

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Beading

-

Type

Internal.

Material

Aluminium.

Finish

-

Coating

Polyester powder-coating.

Texture

Gloss.
Matt.
Satin.
Textured.

Manufacturer guidance

Consult manufacturer for details and insert requirements.

External colour

-

Manufacturer guidance

Insert requirements.

  • Available in standard and non-standard RAL colours.
  • Single and dual colour powder coat as standard, provided by Qualicoat approved supplier.
  • Consult manufacturer for details.

Internal colour

As external.
Other.

Guidance for specification option:

Insert requirements.

  • Available in standard and non-standard RAL colours.
  • Dual colour powder coat provided by Qualicoat approved supplier.
  • Consult manufacturer for details.

Film thickness (minimum)

60 microns as standard.

Door accessories

Letterplate and panels.

Hardware

Multi-point locking (manual locking and auto-engage).
Adjustable hinges.

Accessories

-

Manufacturer guidance

Consult manufacturer for details and insert requirements.

Sustainability data

Material

Aluminium
