Rockpanel Stones
Verified by manufacturer 6 months ago
QA Certificate
Certificate type
Visionary architecture is characterised by a courageous crossing of borders. Overcome limits – even those in nature. Design facades with the powerful look of stone. Build with its strength.
Application
Can be applied in a range of projects including residential and commercial. Typical areas include ventilated rainscreen facades, roofline, soffits and fascias.
Suitable sub frames
Rockpanel Stones in Durable quality can be attached to the building by fixing to a sub frame of metal. Rockpanel Stones in A2 quality can only be attached to a sub frame of aluminium or steel. The minimum thickness of the vertical aluminium profiles is 1.5 mm.
Description
Solid as a rock, yet highly flexible. Rockpanel Stones panels offer you the best of both worlds: they look like stone and have the same fire-resilient qualities, but they can also be bent and curved.
Surface
The surface of Rockpanel Stones is treated with a four-layer water-borne polymer emulsion paint on one side, and comes standard with a ProtectPlus finish. The Rockpanel ProtectPlus boards are provided with an extra anti-graffiti clear coat as a fifth layer on top of the coloured paint.
Fire Safety
The Euroclass-classification of all Rockpanel products is based on testing with non-combustible mineral wool insulation. For the field of application covered by the classification please see the relevant Declaration of Performance. For high-rise buildings and high-risk buildings Rockpanel recommends the application of non-combustible (Euroclass A1-A2) cladding and insulation.
General information
Color | Brown Grey Red Silver Green |
Finish | Anti-graffiti |
Material | Stonewool |
Shape | Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year Guidance for specification option: Ten-year project specific warranty on application |
Uniclass | |
CAWS | G20/950 Fascias/ barges/ soffits G20/99 Fascias/ barges/ soffits H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H20/150 Sheet cladding (attached to metal support systems) H20/155 Sheet cladding (attached to timber battens) H92/120 Rainscreen cladding L10/510 Glazed wood screens L10/550 Glazed metal screens L10/56 Glazed screen system L10/560 Glazed screen system |
Specification data - Compressed rock fibre panels
Third-party product certification | certification ETA-07/0141 or ETA-13/0340 - Dependent on variant specified. |
Panel size | |
Length | 2500 mm3050 mmCustomGuidance for specification option: Consult manufacturer and insert requirements. |
Width | 1200 mm |
Panel thickness | 9 mmGuidance for specification option: Rockpanel Stones A2 only. 11 mmGuidance for specification option: Rockpanel Stones A2 only. |
Edge profile | Square edge |
Finish as delivered | ProtectPlus |
Colour | Manufacturer guidanceInsert requirements. |
Reaction to fire | |
Panel internal face | European fire class A2-s1,d0 - Dependent on variant specified. |
Panel external face | European fire class A2-s1,d0 - Dependent on variant specified. |
Product Reference | Rockpanel Stones A2 Guidance for specification option: Reaction to fire: European fire class A2-s1,d0. |
Combustibility | European fire class A2-s1,d0 Dependent on variant specified. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Netherlands |
Country of product manufacture | Netherlands |
Material | Stonewool |
Recyclability | Recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 50 % |
Third party certifications
Literature
Rockpanel Stones - Built to last
