RootRain Urban - Large-capacity Tree Irrigation/ Aeration

Verified by manufacturer 2 months ago

RootRain Urban RRURB1A

GreenBlue Urban Ltd Variant:

A large-capacity tree pit irrigation and aeration system for soft landscaping.

Jump to:
+44 (0)1580 830800 Website

Application

Large-capacity tree irrigation and aeration system for soft and hard landscaping for all newly planted trees.


A regular watering schedule is essential for newly planted trees during the first 3-5 years until they become established, particularly during the hotter summer months.

Description

A large-capacity tree irrigation and aeration system for soft and hard landscaping, with a fixed, non-removable grid inlet, available in three sizes, ensuring water ingress around the rootball rather than being held in the upper layers of soil or running off. By watering the rootball you are encouraging roots to run deeper and not near the surface where they will be prone to drought.


Features and benefits:

  • Comprises a perforated plastic ring pipe and a grid inlet.
  • 100 litre per minute capacity in porous soil
  • The grid allows water and air through but prevents ingress of litter and debris.
  • Inlet and T-piece 100% recycled plastic
  • The inlets are strimmer resistant and can be set below mowing machine height.
  • Vandal resistant.
  • Automatic irrigation connection adapter available
  • The vertical piece of pipe can be cut to length to ensure that the inlet is flush or slightly (25 mm) proud of the final tree pit surround.

General information

Color

Black

Finish

Satin

Material

Polyethene

Shape

Circle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Six year

Uniclass

Pr_70_55_42_90 Tree irrigation and aeration unitsPrimary
Ss_55_70_42_60 Passive irrigation and aeration systems

CAWS

S14/110 Irrigation system

Q31/512 Tree pit irrigation and ventilation accessories

Specification data - Tree irrigation and aeration units

Description

A large-capacity tree pit irrigation and aeration system.

Manufacturer

GreenBlue Urban Ltd.

Pipe

-

Material

Polypropylene.

Colour

Black.

Circumference

2.5 m.

Diameter

60 mm.

Recycled content (minimum)

100%.

Water inlet

-

Number

One.

Type

Grille inlet, PE-HD moulded grid top, 80 mm diameter.

Guidance for specification option:

Reducer: 80/60 mm HDPE with integral strengthening fins.

Vertical pipe: As irrigation hose.

Tee section: Heavy-duty HDPE with non-return locking lugs to secure pipework.

Inlet

Automatic irrigation system adapter.

Accessories

None.

GBUAIWAA - Automatic Irrigation Adaptor.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Polyethene

Recyclability

100% recyclable

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

100 %

Expected Life

50 year

Literature

GBU RootRain Urban Datasheet

GBU RootRain Urban Datasheet

RootRain Urban irrigation system

RootRain Urban irrigation system
