Securi-Mesh® Plus Fencing - Double layer mesh security fencing

Verified by manufacturer 5 months ago

Jacksons Fencing Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

Climb-resistant double-layer mesh fencing.

Jump to:
0800 408 4757 Website

Application

Suitable for high security perimeter and access control applications such as prisons, utilities, data centres and transport.

Description

Climb-resistant double-layer mesh fencing. Has small apertures and welds at each intersection, which eliminate foot and finger holds and also prevent objects being passed through. It is effective against the use of conventional hand and portable power cutting tools.


Features and benefits:

  • Can accommodate barbed/ razor wire, Alarm-aFence® and Rota-Spike.
  • Can be adapted to mount CCTV cameras or lighting.
  • Can be stepped for sloping or uneven ground.
  • Exceeds UK prison specifications.
  • Overlapped by a minimum of 75 mm at posts to maintain integrity of protection.
  • Staggered double skin mesh panels with wire welded at every intersection.
  • Suitable for incorporation of Jaktronic Perimeter Intruder Detection System (PIDS).
  • Vandal proof connectors.
  • 25-year guarantee.

General information

Color

Silver

Green

Black

Other

Finish

Galvanized

Powder-coated

Material

Steel

Shape

Rectangle

Width

2440 mm

Height

1270 mm

2134 mm

2440 mm

3000 mm

4200 mm

Show more

Warranty description

25 year

Uniclass

Ss_25_14_61_51 Metal mesh panel fencing systemsPrimary

CAWS

Q40/125 Open mesh steel panel general purpose fencing

Q40/126 Open mesh steel panel security fencing

Q40/27 Open mesh steel panel general purpose fencing

Q40/30 Proprietary fencing

Q40/430 Proprietary fencing

Product range

Mesh Security Fencing

Specification data - Metal mesh panel fencing systems

Standard

Can be configured to meet Home Office specifications for prison use.

Category

3.

Guidance for specification option:

High-security welded mesh fencing,

Posts

Rectangular hollow section (RHS) with tamper resistant bolts.

Guidance for specification option:

Post centres: 2440 mm.

Post foundations

Over length set in concrete.

Guidance for specification option:

As standard.

Base plated to bolt down onto concrete.

Cranked to suit wall mounting.

Panels

-

Manufacturer guidance

Insert height requirements, 1270–5200 mm.

2515 mm wide, staggered double skin of 76.2 x 12.7 mm. Mesh wire: 4 mm thick.

Fence topping

None.

Rota spike.

Cobra spike.

Cobra spike rotary.

Viper spike.

Barbed wire.

Razor wire.

Jaktronic perimeter intruder detection system (PIDS).

System accessories

None.

Matching gates.

Guidance for specification option:

Single and double gates available, specified separately.

Finish/ Colour

Galvanized.

Guidance for specification option:

Standard.

Zinc alloy coated and powder coated, black RAL 9005.

Guidance for specification option:

To BS EN 13438.

Zinc alloy coated and powder coated, green RAL 6005.

Guidance for specification option:

To BS EN 13438.

Zinc alloy coated and powder coated, other.

Guidance for specification option:

Special order, insert requirements (BS or RAL code).

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Third party certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001:2015 Quality Management System
