Sensorflow 21 - Cast Spout With Built-In Sensor
Verified by manufacturer over a year ago
A deck-mounted single mixer tap with tall spout and sensor operation.
Application
Suitable for commercial use.
Description
A range of compact water saving vandal resistant sensor operated hands-free electronic basin mounted spouts used where there is a demand for hygiene and water saving.
Sensorflow 21 washbasin panel mounted tap with 150 mm cast spout with integral sensor, flexible inlet tail, solenoid valve, combined servicing valve and filter, sensor and solenoid cables and flex connectors and mains supply.
Features and benefits:
- Laminar flow.
- Chrome plated.
- Hands-free operation.
- Anti-vandal outlet housing.
- Hygienic "no touch" operation.
- Designed to be supplied with pre-mixed water.
General information
Color | Silver |
Finish | Chrome |
Material | Brass |
Length | 171 mm |
Warranty description | Five year |
Uniclass | |
CAWS | N13/335 Washbasins N13/30 Washbasins N11/350 Sinks, taps, traps and wastes |
Specification data - Washbasin manual water supply sets
Approval | Water Regulations Advisory Scheme (WRAS)-approved. |
Form | Sensor mixer tap. |
Materials | |
Body | Brass. |
Finish and colour | Chrome-plated.Chrome, ultra steel. |
Flow rate (maximum) | 4.7 L/minute at 3 bar. |
Integral accessories | Sensors.Guidance for specification option: Spouts with integral sensors detect hands within the sensing range and the solenoid valve is opened. Automatically shuts off if sensor is obstructed for a maximum of 50 seconds. Transformer.Guidance for specification option: Mains powered transformer with option to link up to 5 link units per main unit alternatively there are stand alone battery powered units. Solenoid valve.Servicing valves.Guidance for specification option: Individual solenoid valve, copper tube inlet and combined servicing valve and filter. Copper tube inlet. |
Mounting | Wall mounted. |
Accessories | None. Low pressure flow straightener. Guidance for specification option: Optional low pressure flow guide will deliver 3.3 litres per minute at 0.1 bar. |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
