Supreme F30 - Heavy Duty Retractable Ladder - Fire Rated Wooden Hatch - Retractable ladder

Verified by manufacturer 1 month ago

Premier Loft Ladders Ltd

Fire-rated heavy duty retractable loft ladder. Insulated wooden hatch offering 30-minute fire protection.

Jump to:
BOS
+44 (0)345 9000195 Website

Application

Loft applications.

Plant room applications.

Description

The Supreme F30 Wooden Hatch box fire resistant loft ladder tested according to EN 1363-1, EN 1634-1 and ÖNORM B 3860 by IBS Linz for fire resistance of 30 minutes from below (EI230). The heavy-duty aluminium retractable loft ladder is supplied as a ready to fit unit. It manufactured from high strength die-cast aluminium alloy components contained within a fire-resistant hatch box manufactured from high-quality B1 chipboard.


The counter-balance mechanism allows you to raise and lower the ladder with a minimum of effort (operating force of less than 3 kg). Large steps and pre-assembled telescopic handrail offer comfort, safety and ease of access.


Features and benefits:

  • High strength aluminium retractable ladder.
  • Heavy duty load rating (200 kg per tread).
  • Insulated trap door / hatch box (0.80 W/m²K).
  • Very easy to operate (less than 3 kg operating load).
  • Tested for 30 minutes fire resistance.
  • Class 4 certified airtight seal.
  • Telescopic handrail and anti-slip treads to provide comfort and safety.
  • Low maintenance with excellent durability.
  • Supplied ready to install.

General information

Color

White

Guidance for specification option:

Hatch box.

Silver

Guidance for specification option:

Aluminium ladder.

Material

Aluminium

Guidance for specification option:

Ladder.

Wood

Guidance for specification option:

Hatch box.

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

2500 mm

2790 mm

3090 mm

3390 mm

3690 mm

Manufacturer guidance

Maximum heights. Minimum aperture sizes apply.

Warranty description

Two year

Guidance for specification option:

Full manufacturers warranty.

Ten year

Guidance for specification option:

Parts warranty.

Uniclass

Pr_25_30_85_03 Aluminium loft laddersPrimary

CAWS

L30/421 Loft ladders

L30/41 Loft ladders

Product range

Fire Rated Loft Ladders
Heavy Duty Retractable Concertina Loft Ladders

Specification data - Aluminium loft ladders

Standard

To EN BS EN 14975, ÖNORM 3860, EN 1634-1 and EN 1363-1, EN 12207/ 12114 (Class 4).

Format

Retractable.

Floor-to-ceiling height (minimum)

Up to 2500 mm.

2501–2790 mm.

2791–3090 mm.

3091–3390 mm.

3391–3690 mm.

Treads

Treads between 250–380 mm wide are 140 mm deep. Tread width is dependent upon hatch box width and floor-to-ceiling height.

Loft trapdoor

-

Operating mechanism

Manual.

Hatchbox/ trapdoor material

Wooden EI_2_30.

Guidance for specification option:

30 minutes fire resistance.

Depth

240–680 mm.

Guidance for specification option:

Insert requirement.

Accessories

None.

Additional telescopic handrail.

Powder coat finish to aluminium ladder.

Guidance for specification option:

Any RAL code, insert requirements.

Security lock.

Three side upper-level guardrail.

ThermalTransmittance

0.80 W/m²K.

LoadBearingCapacity

200 kg.

Guidance for specification option:

Per tread.

Sustainability data

Contains Red List materials

No

Manufacturer guidance

Contains Pentachlorophenol in compliance with EN 13986 (<5ppm) and fulfils class E1 Formaldehyde.

Country of product manufacture

Germany

Material

Aluminium

Guidance for specification option:

Ladder.

Wood

Guidance for specification option:

Hatch box.

Manufacturing plant location

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

-

Manufacturer guidance

We hope to be able to publish this data from early 2025.

Recyclability

90% of all materials used in the product and packaging are recyclable.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

-

Manufacturer guidance

Data currently unavailable.

Expected Life

30 year

Guidance for specification option:

With correct installation and maintenance.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit
-

1
