Technowood Natural Veneer Coated Aluminium Panels

Name: Technowood Natural Veneer Coated Aluminium Panels
Brand: Technowood UK
SKU: pVKpkNd1EE4wVCyB3teQQ7

Verified by manufacturer 1 month ago

ECP-10

Third party certifications:

Aluminium panels with a natural wood veneer.

Jump to:

Application

Suitable for exterior and interior use in place of timber .

Aluminium panels with the appearance of natural wood.

Complementary finishing and corner profiles are available, specified separately.

Features and benefits:

Provides the visual and tactile effects of natural wood.
Requires 98% less timber than equivalent sold wood projects.
Minimal maintenance required.
Standard length on profiles is 6 metres and can be produced shorter or up to 7.5 metres upon special request.
As a standard, the end points of the profiles are open; and they can optionally be produced as closed with solid wood. Straight or carved options available.
Five colours available as standard; specific colour production can be made for orders above 1000 linear metres.
Veneered GRP panels also available, specified separately.

Benefits of aluminium:

Color	Brown Beige Black Copper Cream Grey Ivory White Other Show more Manufacturer guidance Eight colours available.
Finish	Veneered
Material	Aluminium
Shape	Rectangle
Length	6000 mm
Width	100 mm 150 mm 200 mm
Height	4.5 mm
Warranty description	20 year

Uniclass	Pr_25_71_14_02 Aluminium cassette panelsPrimary Pr_25_71_51_02 Aluminium long strips
CAWS	H92/120 Rainscreen cladding H31/10 Metal H31/120 Metal

Alloy	-
Grade	Manufacturer's standard.
Temper	Manufacturer's standard.
Sheet thickness	Manufacturer's standard.
Panel size	100 x 3200 mm. 100 x 6000 mm.
Finish	-
Material	Natural wood veneer.
Thickness	Manufacturer's standard.
Colour	Teak. Guidance for specification option: Suitable for external environments; water-resistant. High resistance to insects and fungal damage. Mahogany. Guidance for specification option: Hardwood, suitable for varnishing. Multi-purpose. Walnut. Oak. Guidance for specification option: Resistant to weather conditions and humidity. Ash. Bamboo. Manufacturer guidance FSC-certified veneer, applied to four sides as standard. Consult manufacturer if veneer to three sides only is required. Specific colour production can be made for orders above 1000 linear metres; consult manufacturer for details.
Reaction to fire	-
Panel external face	Class A2.
Panel internal face	Class A1.

Product Reference	Technowood Natural Veneer Coated Aluminium Panels - ECP-10 Technowood Natural Veneer Coated Aluminium Panels - ECP-15 Technowood Natural Veneer Coated Aluminium Panels - ECP-20 Technowood Natural Veneer Coated Aluminium Panels - ECPA2-10 Technowood Natural Veneer Coated Aluminium Panels - ECPA2-15 Technowood Natural Veneer Coated Aluminium Panels - ECPA2-20 Show more
Fire rating for panels	A2, s1, d0.
