Tegula Setts | Concrete Block Paving

Verified by manufacturer 3 months ago

Tobermore Third party certifications:
  • EPD

    EPD

    Certificate type

Aged appearance block paving cobble setts.

Jump to:
+44 (0)844 800 5736 Website

Application

For block paving applications.

Description

Aggregate paving setts with a granite appearance. A special tumbling process removes hard edges, giving the impression that the area has been paved for decades.


Features and benefits:

  • The setts blend with rumbled products like Tegula and Retro or can provide contrast to the modern finishes of Sienna or Shannon.
  • Tegula Setts can also be used independently to create a cobbled effect.
  • BREEAM rating A (A+ with recycled sub-base).

General information

Color

Gold

Other

Guidance for specification option:

Charcoal.

Finish

Tumbled

Material

Concrete

Shape

Square

Length

100 mm

Bespoke

Guidance for specification option:

Various.

Width

100 mm

Height

50 mm

Uniclass

Pr_25_93_60_22 Concrete settsPrimary

CAWS

Q24/110 Conventional concrete block paving

Q24/112 Conventional concrete block paving with bound base

Q24/113 Conventional concrete block paving overlay

Q25/150 Concrete sett paving system

Product range

Tobermore Paving Blocks I Concrete Pavers

Specification data - Concrete setts

Physical properties

-

Colour

Charcoal.

Golden.

Finish

Aged appearance, old cobbled effect.

Nominal sizes

100 x 100 x 50 mm.

Bespoke.

Guidance for specification option:

Various lengths x 100 x 50 mm; consult manufacturer.

Recycled content (minimum)

10%.

Guidance for specification option:

(No less than 10%).

Standard

To BS EN 1338: 2003.

Strength

Not less than 3.6 MPa.

Manufacturer guidance

Characteristic tensile splitting strength.

Slip resistance

Mean polished skid resistance value (PSRV): >45.
Mean unpolished skid resistance value (USRV): >45.

Efflorescence

Minimum 12 hour vapour curing to reduce significantly the possibility of efflorescence.

EnergyUsed

100%.

WaterUsed

100%.

BREEAM rating

A (A+ with recycled sub-base).

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

12.35 kg CO₂ eq/m²

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

10 %

Manufacturer guidance

Not less than 10%.

Third party certifications

Third party certifications

EPD

EPD

Environmental Product Declaration (EPD)- Hydropave Tegula 240, Hydropave Tegula Duo 60mm, Retro 60mm, Tegula , Tegula Setts, Tegula Trio, Kingston 215x100x65mm, Lansdowne 215x100x65mm, Kerbstone

Case studies

Denbigh School, Milton Keynes - GSS Architects

Denbigh School, Milton Keynes - GSS Architects

The Old Brewery

The Old Brewery
