Tegula Trio | Concrete Block Paving
Verified by manufacturer 3 months ago
EPD
Certificate type
Concrete paving block with aged, antique appearance.
Application
For block paving applications, ideal for landscape schemes where aesthetics and style are primary considerations.
Description
Concrete paving blocks with an aged appearance. A special tumbling process removes the hard edges, making it appear that an area has been paved for decades. Three sizes in one pack.
Features and benefits:
- The surface is easily trafficked by pedestrians, prams, wheelchairs or vehicles.
- Tegula can match the traditional splendour of a period design or add character to a modern environment.
- BREEAM rating A (A+ with recycled sub-base).
General information
Color | Gold Other Guidance for specification option:
|
Finish | Tumbled |
Material | Concrete |
Shape | Square Rectangle |
Length | 130 mm 173 mm 197 mm |
Width | 173 mm |
Height | 50 mm |
Uniclass | |
CAWS | Q24/10 Conventional concrete block paving Q24/110 Conventional concrete block paving Q24/112 Conventional concrete block paving with bound base Q24/113 Conventional concrete block paving overlay |
Product range |
Specification data - Concrete paving blocks
Standard | To BS EN 1338. |
Physical properties | |
Colour | Bracken.Brindle.Cedar.Charcoal.Golden.Heather.Slate. |
Finish | Tumbled to give an aged appearance. |
Profile | |
Paver type | Square.Rectangular.Manufacturer guidanceCorners and edges broken off to give an aged, antique appearance. |
Dimensions and associated tolerances | |
Nominal sizes | 197 x 173 x 50 mm.173 x 173 x 50 mm.130 x 173 x 50 mm.Manufacturer guidanceAll three sizes in one pack. |
Slip resistance | Extremely low (>75 USRV). |
Skid resistance | Extremely low (>75 USRV). |
Strength | >3.6 MPa. |
Efflorescence | Minimum 12 hour vapour curing to reduce significantly the possibility of efflorescence. |
EnergyUsed | 100%. |
WaterUsed | 100%. |
BREEAM rating | A or A+ with recycled sub-base. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 18 kg CO₂ eq/m² |
Recyclability | 100% |
Third party certifications
Third party certifications
EPD
Environmental Product Declaration (EPD)- Hydropave Tegula 240, Hydropave Tegula Duo 60mm, Retro 60mm, Tegula , Tegula Setts, Tegula Trio, Kingston 215x100x65mm, Lansdowne 215x100x65mm, Kerbstone
Case studies
Aldermans Green Community Primary School
Rosther Hill Developments, Beswick Green
