TSL.970 Wall Mounted Manual Tap
Verified by manufacturer 23 days ago
TSL.970.CS
TSL.970.CS
A wall-mounted manual tap.
Application
Suitable for washrooms.
Description
The TSL.970 is a wall-mounted manual tap with a spout and an accompanying lever-operated mixer. Available in a range of finishes.
Features and benefits:
- Minimalistic wall-mounted tap.
- Integrated flow and temperature adjustment valve.
- Multiple flow rates available.
- BREEAM/ LEED compliant for water conservation.
- Brushed stainless steel with four PVD colours.
- Available in 150 mm length – please enquire.
General information
Color | Silver Black Gold Guidance for specification option: Brass. Copper Bronze |
Finish | Satin PVD Brushed |
Material | Stainless steel |
Shape | Other |
Length | 227.79 mm |
Width | 120 mm |
Height | 92.25 mm |
Uniclass | |
CAWS | N13/30 Washbasins N13/335 Washbasins |
SKU Code | TSL.970.CS, TSL.970.BK, TSL.970.BR, TSL.970.CP, TSL.970.BZ |
Specification data - Washbasin taps
Approvals | KIWA certified. Guidance for specification option: Certificate No. 2409750. |
Form | Wall-mounted mixer tap. |
Materials | |
Body | AISI 304 stainless steel. |
Finish and colour | Satin stainless steel. |
Flow rate (maximum) | 3.8 L/min - Cascade flow; 1.9 L/min - Spray flow. 3.8 L/min - Cascade flow; 1.35 L/min - Spray flow. |
Water supply temperature (maximum) | User-controlled. Guidance for specification option: Water temperature (maximum): 60°C. |
Colour (Light reflectance value (LRV) | 58. |
Sustainability data
Material | Stainless steel |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
TSL.970_Wall_Mounted_Manual_Tap_Datasheet_EU_V3
