Application

Suitable application environments include; petrol stations, shopping centres, airports, industrial buildings, schools, residents, offices, stadiums, hospitals, cargo and passenger vessels, high humidity areas, airports, parking lots, military buildings, hotels, factories, stations and restaurants.

Description

Aluminium linear suspended ceiling system.


Features and benefits:

  • Manufactured from aluminium.
  • Perforated.
  • Soundtex under acoustic felt.
  • Suitable for multiple uses.
  • Standard colour RAL 9016.

General information

Color

White

Other

Finish

Painted

Material

Aluminium

Shape

Rectangle

Square

Rhombus

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Ss_30_25_22_47 Linear ceiling lining systemsPrimary

CAWS

K40/115 Unit/ modular suspended ceiling system

K40/10 Unit/ modular suspended ceilings

Specification data - Linear ceiling lining systems

Ceiling support

Metal suspended ceiling hangers.

Support fasteners

-

Manufacturer guidance

Consult manufacturer for details.

Linear strip

Metal finishing batten (30 - 80 - 130 - 180 B).

Barriers in ceiling void

-

Fire barriers

Not required.

Acoustic barriers

Soundtex felt.

Material

0.4–0.7 mm Aluminium.

Manufacturer guidance

Panel material.

Perforation

Ø1.2–2 mm.

Colour

RAL 9016.

Guidance for specification option:

As standard.

RAL colour.

Guidance for specification option:

Optional; insert requirements.

Sustainability data

Contains Red List materials

No

Country of material origin

Turkey

Country of product manufacture

Turkey

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0 kg CO₂ eq/unit

Self declared

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %
