UltiSuDS

Verified by manufacturer 6 months ago

Tarmac Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

An integrated sustainable drainage solution.

Jump to:
Website

Application

Developed for use as a pervious pavement system for improved drainage in lightly trafficked environments such as car parks, residential and urban roads.

Description

ULTISuDS BBA HAPAS certified as a porous asphalt surfacing system for use within a pervious pavement for surface water source control, in lightly trafficked areas such as car parks, residential and urban roads.


An integrated sustainable drainage solution which reduces the risk of flooding by managing surface water at source.


By combining engineered porous asphalts and permeable aggregate support layers with other environmental measures like infiltration strips, ponds and swales, rainwater is intercepted and absorbed before it enters the watercourse.


UltiSuDS is designed to capture and control rainwater from the moment as it makes contact with the porous paved surface. This results in significant reductions in the speed and volume of discharged water, reducing the risk of flash flooding.


Features and benefits:

  • Achieves a hydraulic conductivity rating at installation of 5000 mm/hr.
  • As part of a sustainable drainage solution, it meets the requirements of planning regulations and the Code for Sustainable Homes.
  • Enhanced safety for vehicles and pedestrians by reducing standing water and ice.
  • Traps and retains pollutants like hydrocarbons and heavy metals.
  • When water storage measures are available it can aid water harvesting and re-use.

General information

Color

Black

Finish

Guidance for specification option:

Porous asphalt with open aggregate structure.

Material

Asphalt

Warranty description

Five year

Uniclass

Pr_35_31_05_65 Porous asphalt concrete (PAC) surface coursesPrimary

CAWS

Q22/127 Porous asphalt concrete paving

Specification data - Porous asphalt concrete (PAC) surface courses

Standard

To BS EN 13108

Target composition

-

Designation

Guidance for specification option:

Contact manufacturer for details.

Binder grade

Guidance for specification option:

Contact manufacturer for details.

Colour

Black.

Aggregate properties

-

Resistance to polishing - polished stone value (minimum)

Guidance for specification option:

Aggregate PSV selected specifically for each contract 50+.

Third-party certification

09/H143.

Type:

10 mm aggregate size surface course porous asphalt and 20 mm and 32 mm aggregate size porous binder course.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

kg CO₂ eq/unit

Self declared

Guidance for specification option:

Consult manufacturer for details.

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

%

Guidance for specification option:

Contact manufacturer for details.

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

TARMAC POROUS ASPHALT SURFACING SYSTEM - UltiSuDS - 09/H143
