Ultraflo® – Liquid hemihydrate screed - Hemihydrate Liquid Screed

Verified by manufacturer 2 days ago

RTU Ltd

A calcium sulphate, hemihydrate, pump applied liquid floor screed

Jump to:
+44 (0)28 9085 1441 Website

Application

  • Sub-floor levelling.
  • For use with underfloor heating systems.
  • Unbonded, bonded and floating floor constructions.
  • Suitable for both residential and commercial floors.
  • Not suitable for areas which are in regular contact with water e.g communal showers, wet rooms, exterior yards or similar

Description

A calcium sulphate, hemihydrate, pump applied liquid floor screed.

The product has been designed to comply with BS EN 13813, screed material and floor screeds, screed material - properties and requirements.

The product has minimal drying shrinkage. Movement joints need only to be considered where the floor exceeds 1000 m², or where the floor becomes elongated and an aspect ratio of 1:6 is exceeded. Movement joints should also be considered across doorways. When used with underfloor heating systems, movement joints should be considered between different heating zones or when the floor exceeds 300 m².

The flowing characteristics means it is self-compacting thus voids and poor compaction are virtually eliminated.

As with virtually all screeds, it is not a wearing surface and therefore requires a suitable floor covering. Can be used with all standard floor coverings i.e tiles, wood, carpet and vinyl.

Features and benefits:

  • Very low shrinkage; does not curl.
  • Movement joint requirement greatly reduced.
  • Can be walked on 24 hours after application.
  • Increased productivity – 2000 m² per day can be achieved.
  • Significantly reduced thickness when compared to traditional sand:cement screeds.
  • Reduced drying times due to reduced depth and weight.
  • Can be force dried.
  • Underfloor heating system can be turned on after 7 days.
  • Increased efficiency of underfloor heating system.
  • Quicker heat response time with underfloor heating.

General information

Color

Beige

Finish

Smooth

Material

Calcium sulphate

Shape

Formless

Uniclass

Pr_35_31_06_71 Ready-mixed levelling and wearing screedsPrimary
Pr_35_31_06_78 Self-smoothing levelling screed mixes

CAWS

M10/19 Proprietary screeds to BS EN 13813

M10/195 Proprietary screeds to BS EN 13813

M10/160 Proprietary self smoothing levelling screeds

Specification data - Ready-mixed levelling and wearing screeds

Classification data

Standard

To BS EN 13813

Binder type

Calcium sulfate.

Flexural strength

>4 N/mm².

FireRating

Non-combustible.

ThermalConductivity

1.66–1.88 W/mK.

Minimum application thickness

-

Manufacturer guidance

Insert requirements:

  • Bonded – 25 mm.
  • Unbonded – 30 mm.
  • Floating (Commercial) – 40 mm.
  • Floating (Domestic) – 35 mm.
  • Underfloor Heating – 25 mm (minimum to cover pipes).

Shrinkage

<0.02%.

Flowrate

230–250 mm (DIN 1060 Test).

Linear thermal expansion coefficient

0.01 mm/mK.

Sustainability data

Material

Calcium sulphate

Literature

Ultraflo® Technical Data Sheet

Ultraflo® Technical Data Sheet
