Urban Bollard

Verified by manufacturer 5 months ago

Urban bollard Ø76, anchoring with base plate - 585-900A

Vestre Variant:
Third party certifications:
  • ISO 14001 Environmental Management Systems

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • FSC

    FSC

    Certificate type

Steel bollard available in two diameters and various anchoring options.

Jump to:
+44(0)207 846 8725 Website

Application

Suitable for outdoor use.

Description

Urban bollard comes in two sizes and can be supplied with or without a chain or rope attachment.


Features and benefits:

  • Part of the Urban range.
  • Two diameters - Ø76 mm and Ø127 mm.
  • Base plate, concreted or demountable options.
  • Award for design excellence.
  • Lifetime warranty against rust.
  • 15 year warranty on powder-coating.
  • Spare parts are available if required.
  • Corrosion class C5-M.
  • Nordic Swan Ecolabel, Intertek and Climate Compensated Organisation certifications.

General information

Color

Grey

Other

Guidance for specification option:

Powder-coating available in over 200 RAL colours. Consult manufacturer and insert requirements.

Finish

Galvanized

Powder-coated

Material

Steel

Shape

Other

Width

76 mm

127 mm

Height

900 mm

Uniclass

Pr_20_76_08_10 Carbon steel bollardsPrimary

CAWS

Q50/196 Removable bollards

Q50/31 Bollards

Q50/190 Bollards

Specification data - Carbon steel bollards

Dimensions

-

Size and profile

Ø76 mm.

Height

900 mm.

Post top

Flat.

Post base

Base plate.

Guidance for specification option:

Type A - Base plate.

Finishes

-

Applied finish

Hot-dip galvanized.

Hot-dip galvanized and powder-coated.

Colour

Grey.

Guidance for specification option:

Galvanized finish.

RAL colour.

Guidance for specification option:

Powder coated finish, consult manufacturer and insert requirements.

Accessories

Chain attachment.

Guidance for specification option:

Consult manufacturer and insert requirements.

Rope attachment.

Guidance for specification option:

Consult manufacturer and insert requirements.

Not required.

Weight

8 kg.

Sustainability data

Contains Red List materials

No

Country of material origin

Europe

Country of product manufacture

Europe

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

26.66 kg CO₂ eq/unit

Self declared

Guidance for specification option:

585-900A - 26.66 kg CO2.

585-900C - 26.66 kg CO2.

588-900A - 59.68 kg CO2.

588-900C - 53.62 kg CO2.

Manufacturer guidance

Depending on model.

Recyclability

Partly recyclable

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

2.69 %

Third party certifications

Third party certifications

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management Systems

ISO 14001

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001

FSC

FSC

FSC Chain of Custody Certificate
