Urban Seat
Verified by manufacturer 6 months ago
Urban seat, anchoring with base plate - 513-900A
Urban seat, anchoring with base plate - 513-900A
ISO 9001 Quality Management
Certificate type
Steel and wood outdoor seats, available with or without a backrest and armrests.
Application
Suitable for outdoor use.
Description
Urban seat is available with or without a backrest and armrests. Outstanding comfort makes the Urban seat a natural first choice for many projects.
Features and benefits:
- Part of the Urban range.
- Modular solutions.
- Award for design excellence.
- FSC-certified timber.
- Lifetime warranty against rust.
- 15 year warranty on powder-coating and wood.
- Spare parts are available if required.
- Nordic Swan Ecolabel, Intertek and Climate Compensated Organisation certifications.
General information
Color | Grey Other Guidance for specification option: Powder-coating available in over 200 RAL colours. |
Finish | Galvanized Powder-coated |
Material | Steel Wood |
Shape | Rectangle |
Length | 1710 mm |
Width | 675 mm |
Height | 780 mm |
Warranty description | Lifetime Guidance for specification option: Lifetime warranty against rust. 15 year Guidance for specification option: 15 year warranty on powder coating and on wood. |
Uniclass | |
CAWS | Q50/34 Seats Q50/225 Seats |
Specification data - Street and site seats
Length | 1710 mm. |
Base | Two base plates.Guidance for specification option: Type A - Base plate. |
Material | Steel. |
Finish as delivered | Hot-dip galvanized.Hot-dip galvanized and powder-coated. |
Colours | Grey.Guidance for specification option: Galvanized finish. RAL colour.Guidance for specification option: Powder-coating available in over 200 RAL colours. Consult manufacturer and insert requirements. |
Film thickness (minimum) | 3 mm.Guidance for specification option: Hot-dip galvanized and powder-coated steel. |
Accessories | Urban armrest pair - 525-900.Guidance for specification option:
Not required. |
Wood species/ Finish | Linseed oil proofed Nordic pine. Guidance for specification option:
|
Weight | 49 kg. |
Height | 780 mm. Guidance for specification option: 450 mm seat height from ground. |
Width | 675 mm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 81.64 kg CO₂ eq/unit Self declared Guidance for specification option: 513-900A - 81.64 kg CO2. 513-900C - 86.75 kg CO2. 516-900 - 90.07 kg CO2. Manufacturer guidanceDepending on model. |
Recyclability | Partly recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 1.66 % Guidance for specification option: 513-900A - 1.66%. 513-900C - 1.5%. 516-900 - 1.72%. Manufacturer guidanceDepending on model. |
Third party certifications
ISO 9001 Quality Management
ISO 9001
