Vibratek® HS-1 Spring Hanger
Verified by manufacturer 20 hours ago
2800600050
2800600050
Spring isolator.
Application
For light suspended loads. Recommended for equipment with low working speeds, above 700 RPM.
Description
High performance spring isolator.
Features and benefits:
- Simple to install and does not need to be fixed to the base material.
- Epoxy powder-coated housing, cap and spring provide increased resistance to corrosion.
- Rubber spring base cup prevents contact between housing and the spring.
General information
Color | Black Green |
Finish | Epoxy |
Shape | Rectangle |
Length | 65 mm |
Width | 60 mm |
Height | 105 mm |
Uniclass | |
CAWS | K11/27 Acoustic separating floor system K11/275 Acoustic separating floor system |
Specification data - Spring isolators
Spring isolators type | Caged. |
Colour code | Green. |
Load | 5—50 N. |
Deflection | 23 mm (maximum). |
Sustainability data
Country of product manufacture | Netherlands |
Literature
Walraven VibraTek® Brochure
Walraven VibraTek® HS-1 Spring Hanger Data Sheet
Case studies
Case study - heavy duty pipe supports
