Wall Sounders or Wall Sounder Beacons Short-circuit Isolator Base (Red)
Verified by manufacturer 2 months ago
Certificate of Approval cdfa
Certificate type
A mounting base for Wall Sounders or Wall Sounder Beacons featuring integral short-circuit isolator.
Application
Short-circuit isolator applications:
- Schools & Universities
- Multiple Occupancy Accommodation
- Hospitals / Care Homes
- Office Buildings
- Airports
- Rail / Tube Stations
- Hotels / Pubs & Hospitality
- Retail / Supermarkets
- Factory / manufacturing plants
- Hazardous Areas
Description
The YBO-R/SCI Isolator Bases are fully compatible with Hochiki’s ESP analogue addressable protocol. Available in red, the bases have been designed for use with red
Wall Sounders (CHQ-WS2) or Wall Sounder Beacons (CHQ-WSB2).
The bases incorporate an amber LED to show when they are isolating a section of the loop. The bases do not use an address, and have the same wiring configuration as the standard YBN-R/3 sensor mounting base, making them
simple to install.
Features and benefits:
- Detects short circuits on loop.
- Status LED.
- Connection of up to 127 per loop.
- Bayonet slot, low insertion force for detectors.
- Quick Connection via square cable clamps.
- Colour matches with CHQ-WS2 Wall Sounder and CHQ-WSB Wall Sounder Beacon.
General information
Color | Red |
Finish | Gloss |
Material | Plastic |
Shape | Circle |
Length | 13 mm |
Width | 100 mm Guidance for specification option: Diameter |
Height | 100 mm |
Warranty description | Three year |
Uniclass | |
CAWS | W90/326 Point flame detectors |
SKU Code | 1426050-00 / YBO-R/SCI(RED) |
Specification data - Short circuit isolators
Third-party certification | LPCB-approved. |
Mounting | Base. |
Enclosure | |
Material | ABS plastics. |
Colour | Red. |
Voltage | 17–41 V d.c. |
Current | Quiescent Current (typical) 50 μA. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Manufacturing plant location | |
Material | Plastic |
Expected Life | Three year |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Product certifications
Certificate of Approval cdfa
Certificate of Product Approval - EN54-18 | Products: CHQ non SCI and YBO-R/6
Certificate of Approval cdfa
Certificate of Product Approval - EN 54-3 and EN54-23 | Products: CHQ-WSB2, YBO-BSB2 and YBO-BSB3 | Bases: YBN-R/3, YBO-R/3 and YBV-R/4
Certificate of Approval cdfa
Certificate of Product Approval - EN 54-3 | Products: YBO-BS and CHQ-WS2 | Bases: YBN-R/3, YBO-R/3 and YBV-R/4
Certificate of Approval cdfa
Certificate of Product Approval - EN 54-5 - DCD, DFJ, DFG and ACB - Bases YBN-R/3, YBN-R/4 YBN-R/6, YBO-BS, YBO-R/6, YBF and YBO-BSB2
Certificate of Approval cdfa
Certificate of Product Approval - EN 54-7 - ALN-E and ALN-EN - Bases YBO-R/4, YBO-BS, YBN-R/3 and YBO-BSB2
