Welsh Slate Natural Slate Paving

Verified by manufacturer 7 months ago

Penrhyn Heather Welsh Slate

Welsh Slate Variant:

Natural slate paving.

Jump to:
BOS
+44 (0)1248 600656 Website

Application

  • Suitable for commercial and residential areas.
  • Suitable for all types of external public and private projects.
  • Suitable for use in both trafficked and pedestrian areas.
  • The smaller paving units are also suitable for heavy goods vehicle trafficking.

Description

Welsh Slate paving is available in two colours; Penrhyn Heather, with subtle tones of purple, blue and sometimes shades of red and Cwt-y-Bugail Dark Blue Grey, rich deep colours of blues and greys


The colours are complimented with natural variation in tones and shades, and naturally occurring veins and textures, and the natural riven finish gives a textured appearance.


Paving is naturally split and then machined to produce a uniform, calibrated thickness whilst having a 'riven' natural appearance. Its natural grain provides slip resistance as well as a genuine appearance.


Features and benefits:

  • Sustainable natural material with little or no processing and will last for hundreds of years.
  • Ecological friendly.
  • Traditional UK building material used for hundreds of years.
  • Low carbon footprint.
  • 100% natural.
  • Excellent slip resistant properties.
  • Extremely hard and durable stone.
  • High flexural and compressive strengths.
  • Unfading colour.
  • No freeze thaw issues.
  • Welsh slate is totally inert and will repel all elements.
  • Chemically inert, highly resistant to acids, alkalis, and other chemicals.
  • Unaffected by normal extremes of temperature, frost and UV resistant.
  • Unaffected by fungi, moss, insects, animals, or birds.
  • Stain resistant.
  • Nonporous.

General information

Color

Grey

Blue

Manufacturer guidance

Heather Blue and Dark Blue Grey colour tones.

Finish

Natural

Material

Slate

Shape

Rectangle

Square

Length

Bespoke

300 mm

450 mm

600 mm

200 mm

Show more

Width

Bespoke

300 mm

250 mm

Height

Bespoke

20 mm

25 mm

Uniclass

Pr_25_93_60_58 Natural stone paving slabsPrimary

CAWS

Q25/50 Natural stone slabs

Q25/310 Natural stone slabs

Specification data - Natural stone paving slabs

Stone denomination

-

Petrological family

Slate.

Colour

Heather.

Name (traditional)

Penrhyn Heather Welsh Slate.

Origin

Wales.

Physical properties

-

Profile

-

Slab type

Regular plan form.

Arrises

Square.

Dimensions and associated tolerances

-

Nominal sizes

200 x 250 x 25 mm.

300 x 250 x 25 mm.

400 x 250 x 25 mm.

500 x 250 x 25 mm.

Bespoke.

Guidance for specification option:

Consult manufacturer and insert requirements.

Tolerances on plan dimension and thickness (nominal)

+/- 3 mm.

Tolerances on diagonals

+/- 3 mm.

Tolerances on thickness

+/- 3 mm.

Finish

Riven.

Performance requirements

-

Slip resistance

52.79.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %
