Welsh Slate Natural Slate Walling
Verified by manufacturer 7 months ago
Slate walling material.
Application
Suitable for a wide range of external locations.
Description
Slate walling material.
Features and benefits:
- Natural materials.
- Formed up to 590 million years ago, each piece of slate has its own unique appearance.
- Available as rustic walling (striking and rugged) or pillared (smooth and contemporary) walling.
- Extremely hard and durable stone.
- Unfading colour.
- Unaffected by freeze thaw cycles.
- Welsh slate is totally inert and will repel all elements.
- Low carbon footprint.
General information
Color | Blue Grey |
Finish | Sawn Other Guidance for specification option: Pillared, Cleaved, Rustic |
Material | Slate |
Shape | Rectangle |
Length | 200 mm |
Width | 50 mm |
Uniclass | |
CAWS | C41/240 Stone C41/240 Stone F21/110 Ashlar F21/110 Ashlar |
Specification data - Natural dimensioned stones
Standard | To BS EN 12326-1. |
Finish | Heather.Dark Blue Grey.Rustic. |
Additional requirements | |
Durability freeze-thaw | Class 1. |
Mean flexural strength | 53 MPa. |
Thickness | 75 mm. 100 mm. 150 mm. |
FinishType | Pillared. Cleaved. Sawn. Rustic. |
Source | Welsh. |
Length (minimum) | 200 mm. |
Width (minimum) | 50 mm. |
Thermal cycle test | Code T1. |
Carbonate content | 0.03. |
Sulfur dioxide exposure test | Code S1. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
