Claimed to be the largest Passivhaus development to date in the UK and certainly Camden Council’s largest community investment project, Agar Grove Estate, in North West London, is undergoing a six-phase major regeneration due for completion in 2025. The mixed-tenure scheme will provide 493 new homes to help meet Camden's housing needs. There will be a mix of one, two, three and four bedroom homes, with full width balconies on the upper floors. By meeting Passivhaus standard the development will also achieve the highest levels of sustainability and energy efficiency. However, a critical element in any design process involving efficient thermal insulation is the avoidance of thermal bridging. With the Agar Grove development the risk of thermal bridging is primarily at the connectivity points involving balconies and parapets. One of the most technically advanced countermeasures is the Isokorb® range of structural thermal breaks from Schöck. A major reason for the superior performance of this product type is the thickness of the insulation body, increased from the standard 80mm thick to 120mm. High quality stainless steel bars with improved tensile strength are also an integral part of the unit. With parapets, the conventional method is to wrap the perimeter of the wall with an insulation barrier. However, the Schöck Isokorb® used here offers a solution that is more cost-effective and more thermally efficient than wrapped parapets. Its 120mm insulation thickness results in low psi-values and therefore significantly reduces heat loss.

Thermal break for steel-to-steel connection of cantilever elements, transfers tension, compression and shear forces.

A house dating back to around 1910 was dismantled in the St. Johann district of Basel to make way for a new building on the narrow plot. The construction company was forced to allow car, bicycle and pedestrian traffic to continue and had to make do with a building site that was severely restricted.The ten staircase elements were precast in architectural concrete at the factory, treated with Schöck Tronsole® products and shipped to the site where a crane lowered them individually into their exact position in the stairwell through an opening on the top floor. All of which took place without any standard fastening the elements – each weighing two tons – at the sides or on supports. After all, the challenge was to minimise the transmission of impact sound.Installation was performed by the on-site construction manager in Davidsbodenstrasse. It did not take long to win foreman Paul Willig over to the product: "The self-adhesive technology of Tronsole® makes it quick to install, without the need for tools.” Depending on the construction workflow, the impact sound insulation can also be easily applied at the prefabricating plant.

These intriguing high-quality apartments in Vienna, stand out dramatically from neighbouring blocks – and not just because of their blue, orange, yellow and turquoise finish. The large protruding cantilever balconies are a major feature, made possible by incorporating Schöck Isokorb® T thermal break modules throughout. Their outstanding thermal insulation properties dramatically reducing any thermal energy loss, they also transfer load and maintain full structural integrity.

Aylesbury Estate, in South London, has become one of the most significant urban renewal projects in London. There is a new public square at the heart of the regeneration, featuring two separate blocks, from four to fifteen storeys which provide a Community Facility, Public Library, Community Health Care facility and an Early Years Centre.  The sustainability strategy in place for Aylesbury Square is to ‘create a place which meets or exceeds the highest quality standards for a development in London’ – and as the wall connection to the floor or floor slab can be a serious source of linear thermal bridges – the inclusion of the dedicated new Sconnex® type W is a critical addition to the design detailing.  Around 40% of all thermal bridges in a building are caused by walls and supports, resulting in some 10% of heating energy losses. With reinforced concrete construction, minimising linear thermal bridges in these areas has undoubtedly been a perennial problem.  However, the unique new Sconnex® type W offers outstanding insulation performance, combined with an exceptional load-bearing capacity which transmits very high pressure, tensile and shear forces in the longitudinal and transverse direction.  This is made possible by the use of a pressure buffer consisting of ultra-high performance fibre reinforced concrete, which achieves compressive strength in excess of 175 N/mm2 – but with extremely good flexural strength as well.  There is also a significant cost reduction involved when compared to installing insulation beneath the floor slab.

The Canaletto residential tower at 257 City Road in London is located halfway between Old Street and Angel Stations in Islington, alongside the regenerated City Road Basin. It comprises a 31-storey tower with 190 luxury one, two and three bedroom apartments built to the standards of Code 4 Sustainable Homes Level 4.The tower is concrete frame and has a curving facade of metal and glass that breaks the volume into a series of three-to-four storey clusters. In turn, each cluster contains grouped balcony terraces, which are a striking feature of the building. The balconies are of steel construction connected to the concrete frame and as always with cantilever construction elements of this nature, one of the early design considerations had to be the prevention of thermal bridging.For the high specification Canaletto project the Schöck Isokorb® T type SK offers the ideal solution. It is a concrete-to-steel connectivity module that sits between the outer and inner structural connection points and blocks the outflow of heat through the use of high quality polystyrene insulation foam. The Isokorb® T type SK provides a clean and unobtrusive connection detail, minimises on-site assembly time and enables a high level of prefabrication.

Several disciplines are going to be joining forces under one roof in the future university centre for dentistry (UZB) in Basel. A centre of dentistry competence ranging from basic care to research and teaching is being built. Every year, dentists, dental and preventive care assistants and dental hygienists will be administering more than 80,000 treatments in the 5-storey building.The staircases were a key area of focus on this project, both for architectural reasons and in light of the strict sound insulation requirements. All staircases and landings have a bare architectural concrete finish. Compliance with the requirement of an impact sound level delta ΔLn,w* of 28 dB was mandatory in order to protect the quiet areas (e.g. treatment rooms, lecture halls, library, etc.) from distracting noise.Products from the Schöck Tronsole® range have been implemented for acoustic insulation. These impact sound insulation products enable a structural connection of the staircases and landings with no acoustic bridges whatsoever. Correct planning and installation of Schöck Tronsole® in a system results in a blue line visible at the treated areas. It is the mark of quality for reliable impact sound insulation and acoustic bridge-free installation.

Located near Highgate in North London, the Chester Balmore project consists of three elegant brick-clad blocks, housing a contemporary collection of 53 super-insulated one, two and three-bedroom flats, all set around a landscaped courtyard. The development is designed to achieve Code for Sustainable Homes Level 4 and the high levels of insulation employ good use of solar and internal heat gains, plus excellent air tightness and minimal thermal bridges. It is claimed that the air tightness on the Chester Balmore development is around twenty times better than that required by Building Regulations.Preventing thermal bridging along the parapets was a critical consideration for such a high performance development, because as with balconies, parapets can allow conductive materials to transfer energy through the thermal barrier. Conventionally, in the majority of cases, the method of insulating parapets and parapet walls is to wrap the perimeter of the wall with an insulation barrier. However, the Schöck Isokorb® T type A offers a cost-effective and more thermally efficient alternative. Its 60mm insulation thickness results in low psi-values and therefore significantly reduces heat loss – and there is no wrapping required. It offers a more sophisticated construction opportunity for greater freedom of design and offers flexible distance between elements according to load requirements.

The Chiswick Point development, at Bollo Lane, in West London, is a £20m contemporary mixed-use residential scheme offering 124 one, two and three bedroom residential apartments, including three penthouses. A sustainable approach was important, with all of the units designed to meet Level 4 of the Code for Sustainable Homes, and the Lifetime Homes code. Constructed in two blocks of six and nine storeys, the frame is mainly reinforced concrete, with the concrete frame floors and cladding providing thermal mass, which absorbs energy and slowly releases it to help reduce temperature fluctuations.Long continuous ribbon balconies provide solar shading to the two blocks and provide the residents with a very pleasant outlook across the London Wildlife Trust nature reserve at the rear of the development. The continuous balconies are a major feature of the scheme and with several hundred metres of them winding across the two blocks, effective thermal insulation was imperative if thermal bridging is to be avoided. To minimise any condensation problems and subsequent mould growth as a result, plus the avoidance of thermal outflow, Schöck Isokorb® T type K heat-insulating load-bearing elements are installed at various strategic positions along the large expanse of balconies. The Schöck Isokorb® T type K provides high thermal resistance by using stainless steel bars to act as tension and shear reinforcement, plus high-strength HTE pressure bearing modules.

Over the next ten years Nine Elms will see 20,000 homes built, along with new schools, parks, cultural centres, a pedestrian and cycle bridge over the Thames; and the opening of two new London Transport underground stations as part of the Northern Line extension. The residential and commercial heart of this huge development is Embassy Gardens, London's new diplomatic precinct on the riverside. The first release of apartments in Embassy Gardens is the Ambassador Building, adjacent to the new US Embassy. It comprises six distinct cores, which house not only the residential apartments boasting high ceilings, abundant natural light and walnut parquet flooring throughout – but also a fully equipped private members club to rival the best in any international hotel.Inevitably, the development has attracted a sophisticated level of residents who demand the highest standards of detail throughout these buildings; and one of the key features is the wide variety of balcony types, each governed by unit size and orientation. The specific requirements at the Ambassador building involved the Schöck Isokorb® T type K, K-WU an SK. The diverse range of Schöck Isokorb® T load-bearing thermal insulation products guarantees totally verifiable performance standards, meets full compliance with the relevant UK building regulations and offers BBA Certification and LABC Registration.

Forum "Gold und Silber" with its impressively unusual facade incorporating a thermally separated steel structure. The unusual facade with its warm golden colouring and square cut-outs is fastened to a steel substructure that, in turn, is anchored to the reinforced concrete building with Isokorb® T types SK and K. The design of the magnificent envelope made from aluminium slabs with gold-coloured coating is testament to the goldsmithing that has been a traditional craft in Schwäbisch Gmünd for more than six hundred years. The concept envisaged strict separation of the core from the envelope: A multi-angled lightweight structure made of square façade panels coated with a substance that is reminiscent of gold leaf encases the five-floor reinforced concrete skeleton structure measuring 19 x 19 metres. The aluminium skin is set at a distance and features more than 1000 cut-outs of various sizes at interestingly different intervals.Getting a grip on thermal bridgesThe aluminium panels are fastened to a steel frame anchored with Schöck Isokorb® T type SK elements to the load-bearing reinforced concrete skeleton structure. In addition, Isokorb® T type K elements transfer the loads from cantilevered concrete slabs into the concrete structure. Without these load bearing thermal insulation elements, it would not be possible to implement such a facade design nowadays, given the thermal bridges at the joints. Schöck Isokorb® T type SK transfers negative moments and positive shear forces from steel components, such as cantilevered facade substructures, balconies and canopies, to concrete components. Whereas Schöck Isokorb® T type K is designed for cantilever reinforced concrete balconies and concrete slabs. This Schöck Isokorb® T variant also transfers negative moments and positive shear forces.Modern precious metal designAccordingly the Schöck Isokorb® T plays a key role in enabling implementation of the unusual facade design, which turns the building into a striking statement of modern architecture. A total of 767 aluminium panels were used. Their unmistakable, warm golden colouring comes from Duraflon coating, which is enormously resistant to bleaching and colour changes. Depending on the angle of the sun and the position of the observer, the Swabian nugget on the banks of the River Rems shimmers in different shades of metallic gold, while at the same time proving "all that glitters is not gold". Nevertheless, the Forum Gold und Silber still knows how to impress, long after the State Garden Show has finished.

A high-profile project, involving the unique new Sconnex® type W thermally insulating wall connection, is Haberdashers’ Boys’ School, just north of London.   It is one of the UK’s leading independent boys' schools and sets exemplary standards, in both educational terms and in its facilities as well.  Demonstrated by the new reinforced concrete extension to the Preparatory School, where cube_design architects were commissioned to produce a design for three additional classrooms and relocated changing facilities.  Jane Lock-Smith, the founder of cube_design and RIBA Client Design Advisor within the Building Schools for the Future programme, observes: “The design is respectful to the style of the existing building, but offers a contemporary twist through the use of full height glazing and charred timber cladding. A colonnade also minimises the buildings footprint.  Our detailing took into account that around 40% of all thermal bridges in a building are caused by walls and supports.  The Schöck product offers an application-friendly, high-quality solution that contributes to a permanently sustainable building concept”.   The outstanding insulation performance is combined with an excellent load bearing capacity, which transmits very high pressure, tensile and shear forces, both in the longitudinal and transverse direction. The ultra-high performance pressure buffer achieves compressive strength levels in excess of 175 N/mm2. Sconnex® type W also achieves a significant cost reduction when compared with the installation of insulation beneath the floor slab.

The development district now known as London Docklands is an area alongside the River Thames to the East and South East of London. The Harbour Central project involves the construction of a large single storey reinforced concrete basement, high-rise reinforced concrete cores and frames varying in height from 24 to 41 storeys, plus two low-rise reinforced concrete cores and frames.The product used to prevent punching failure throughout the Harbour Central development is the Schöck Bole® reinforcement system. This widely used and trusted Schöck Bole® solution consists of double-headed studs and anchors, with spacing bars, which enable installation after the bottom reinforcement and before the top layer. The two-spacer rods, which are welded to the vertical studs, ensure the correct distance between uprights and the size of the stud heads guarantee a perfect finishing bond with the concrete. As result, when compared with a typical stirrup reinforcement system, an increased shear force resistance of around 70% is achieved. It is cost-effective and timesaving solution and as the Modebest Senior Engineer on site, Sean Togher commented: “The Schöck Bole® product was easy to understand from a reference point of view and we found it really straightforward to install”.

One project with a challenging variety of balconies is Hendon Waterside in North West London, a mixed tenure housing development.  Situated alongside the Brent Reservoir, (known locally as the Welsh Harp, after a public house which used to stand nearby), the scheme involves the regeneration of a 1960s housing estate being built in six phases and scheduled for completion in 2027.  The masterplan will deliver around 2100 new homes consisting of social, affordable and private housing.  These are being constructed in twenty-three blocks, varying in height from three to twenty-three storeys – along with an imposing tower building of twenty-eight storeys. The construction of the many balconies involved vary in their design demands and to ensure the risk of thermal bridging is minimised, Schöck has supplied over thirteen different product variants. The products used here are for concrete-to-concrete and provide optimum solutions through the use of varying tension bar arrangements.  For example one type provides cantilever balcony connections and transfers both negative moments and positive shear forces. Another is a load-bearing thermal break element for transferring shear forces on supported balconies, recessed balconies and for occasional peak shear forces. Others transfer positive shear forces with point support, or transfer positive shear forces with point support and zero stress connection.

Horizons is one of the most recent additions to the skyline on the north bank of the Thames and offers 190 private apartments with stunning views from their substantial private terraces. Two luxury residential developments housed in connected blocks.One of the architectural challenges was to maximise the spectacular panorama and at the same time conserve the local heritage around. The considerable number of balconies involved throughout the development also demanded the minimisation of any possible structural or thermal bridging problems. The Schöck Isokorb® T structural thermal break comfortably met the specification and as the project involved precast balconies, specialists Marble Mosaic had a big part to play as well.The joint MD Dennis Vittle: “This particular project required the balcony units to be not only integral with the main structure, but also insulated and fire-stopped from it. The Schöck Isokorb® T type K was the natural solution. There was a requirement for 345 individual precast balconies throughout the two blocks and the project posed a number of new challenges to MMC’s and the Schöck design team. As well as standard insulated balcony to slab connections there were also a number of downstand and upstand connections required. Also the precast columns were supported off the balcony slab at one end only, so there was a heavy eccentric shear load transfer. The agreed design called for the use of a combination of Schöck Isokorb® T types K and Q to ensure structural integrity with the frame, whilst avoiding any clashes with the concrete frame reinforcement”.

Located in Davos, Switzerland the InterContinental resort and spa consists of a guest building with 216 rooms, and a separate wood-framed building with 38 luxury condominiums. These two buildings are connected by an underground passage, combining the services of a five-star plus hotel with a private home environment.To experience the uninterrupted views of the Landwasser Valley, the InterContinental resort unleashes fully glazed fronts with extending balconies, taking over 882 ft2. The balconies combine the indoor space with the outdoors, visually merging with each other. Yet, in terms of insulation the thermal separations is made to avoid the effects of thermal bridging. Nestled in the Swiss alpine location, construction had to specifically address the fluctuations in temperature and climate.Insulating and SupportingSchöck Isokorb® was incorporated in the balconies to minimize heat losses between the ceiling and the balcony floor. "We have been working with the Schöck products for many years," says Patrick Hager, co-foreman at the construction company Toneatti that occurs along with Baulink AG as the consortium and total contracting.Residences at Minergie® standard (Swiss equivalent for passive house)"To achieve the high insulation goals in this climate, to even the hidden or seemingly insignificant component is an extremely important role to play," found Regina Meier when choosing Schöck products for the balcony constructions in the Residences. Regina is a construction manager at Baulink AG and responsible for compliance with the specifications. "We can at any time, even in the long term, rely on their reliability and durability."

Just a stone’s throw from Baden-Baden’s famous festival hall, a trendy and exclusive hotel has opened its doors in the name of Hotel Roomers. The hotel’s rooftop bar is a stand-out feature. Its lightweight steel canopy connects to the main concrete structure with Schöck Isokorb® type KS elements to minimize thermal bridging in the construction. And when it comes to getting a good night’s sleep, the stairwells are fitted with Schöck Tronsole® to stop impact sound transmissions and ensure a restful stay. The building itself is a hotel, medical centre and apartment block all in one, and its radiant white facade complete with full-height windows creates a striking effect. But the real highlight is how the facade changes its appearance depending on the guests decision to shut out the light in their rooms using the integrated window shading systems. It is not just the facade design that makes this hotel so special, but also its energy concept, which is testament to its ambitious efficiency targets. A crucial component of this concept involved minimising thermal bridges, which were a concern in the hotel’s landmark cantilevered entrance canopy. Without the Schöck Isokorb® type KS elements, it would have been difficult – if not impossible – to build the cantilevered element so efficiently and to decouple the structurally challenging thermal bridge at the point of connection between the freely cantilevered steel girders and the reinforced concrete slabs. All stairwells within the hotel feature the Schöck Tronsole®, which allow it to live up to the high expectations of the investors and building owner Franz Bernhard Wagner in terms of both energy-saving aspects and – of course – sound proofing.

The Höllentalanger, at 1387m, short of halfway during the initial ascent from Germany's highest mountain, the Zugspitze, is a 'hut' millions of climbers have found shelter since 1893. Despite modernisation over the years however, the building had to be closed in autumn 2013.A replacement building was needed – and quickly too. Stephan Zehl, an architect from Munich, won the tender with his three-level, stepped building design. It has pent roof borders, which protects against avalanche risk from the eastern side; and meets all necessary current standards in providing dining facilities, equipment rooms, drying and shoe rooms and comfortable accommodation to sleep 100 people.During autumn and winter, all paths to the Höllentalanger are closed-off, as the Alpine climate makes it impossible to work for eight months of the year. Even in good weather, there are only walking tracks to the Höllentalanger, with no road access at all – so everything had to be flown in by helicopter. Rapid assembly and efficient transport costs were therefore critical to the budget and a combination of timber and pre-cast element walls were the chosen method of construction. Core-insulated prefabricated element walls were supplied for the ground level building. Due to the extreme temperature fluctuations, the concrete is subjected to pretty extreme expansion and contraction conditions. To counter this and to combat thermal bridging, it was important to install Schöck Thermoankers.

Winner of the MIPM 2010 award for Hotels and Tourism, which is presented for outstanding real state projects worldwide, the Kameha Grand was designed by architect Karl-Heinz Schommer Bonner. The unique elliptical section design did however make serious demands on the requirement for protection against thermal bridging. The architect discussed the issue with Schöck, the European specialists in thermal bridging solutions and it was agreed that a combination of three product variants would meet the requirement.The outer concrete arches on the roof and facade of the building cantilever 1.30 m on each side and this, combined with the subtle design of the facade, meant that it was not possible to use a standard thermal break solution. To minimise any thermal bridging problems along the two outer arcs an inventive solution had to be found by the Schöck design team. This was achieved by dividing the projecting element of the framework into a number of sections and using the appropriate Isokorb® T for the required forces. At the ground floor Isokorb® T type Q is used, with T type D being installed higher up the structure, followed by T type K on the top floor. Because of the arch profile, the Isokorb® T type D was cut and installed at 90 degrees and run under the curved edge of the roof emergency exits, providing F90 fire protection.

Kidwells Estate, on the outskirts of Maidenhead in Berkshire, is undergoing major regeneration involving seven new blocks, which are part timber clad and vary from three to six storeys of structural concrete frame. Long cantilever walkways that service multiple flats are a feature of the new development and the unusual design demands of the walkways presented a technical challenge.The solution required a relatively unusual combination of products and Schöck resolved the various issues by designing in its Isokorb® T type HP. It is a product utilised only if horizontal, tension and compression forces are present in the design and additionally it is necessary to integrate the Schöck Isokorb® T types Q-P as well, for linear or point connection to support high shear loads. Schöck Dorn type SLD Q50 heavy duty stainless steel dowels were also incorporated to enable the transfer of vertical shear forces and allow two directional lateral movements at the expansion joints. The result was a completely secure thermally insulated load-bearing connection at all of the restricted, but key structural points.

Kings Crescent Estate, in Stoke Newington, North London is undergoing an ambitious five-year redevelopment project as part of the London Borough of Hackney's wider Estate Regeneration programme. Three new buildings between five and twelve storeys high are under construction, with a number of the existing estate buildings, dating from the 1960s and 1970s, being retained and refurbished to provide continuity and transition. The plan is to recreate a neighbourhood of high quality housing and pleasant tree-lined streets that sits comfortably with the surrounding Victorian townscape of terraced and semi-detached housing close to Clissold Park. There are solar panels, green and brown roofing, plus a combined heat and power plant. These are expected to achieve savings of 25 percent of the carbon dioxide emissions that would otherwise have been generated by the development.The residential element of the scheme will result in up to 765 new homes, intended to offer at least a one-for-one replacement for the present amount of housing on the site. Half the homes will be affordable, with the remainder aimed at the private market. It is claimed to be the only scheme in London to combine new build construction of council homes with the refurbishment of existing council stock.As you would expect there are a significant number of balconies throughout the development and this means the risk of thermal bridging at the many cantilever balcony connections. To counter any such risk, the design incorporates two types of structural break units from the extensive Schöck Isokorb® range.

Located in the heart of the vast new Wembley Park regeneration project, the two residential buildings that make up the Landsby East and Landsby West development (Danish for village) are contemporary in design, with apartment interiors that continue the Scandinavian theme. Externally there are roof terraces and first floor level podium gardens, along with 280 generous balconies that add a stylish and aesthetic feel to the exterior finish of the building.A key element of the balconies was the installation of Isokorb® T structural break units from Schöck. The Schöck Isokorb® T units are structural, but their other long-term purpose is to minimise the risk of thermal bridging. Ineffective insulation at the connection points means local heat loss, resulting in more energy being required to maintain the internal temperature of the building. This is a major consequence of thermal bridging, but there are other issues too. Low internal surface temperatures in the area of the thermal bridge can cause condensation, which leads not only to structural integrity problems with absorbent materials such as insulation products or plasterboard, but the potentially serious occurrence of mould growth. So for any project involving balcony connectivity the prevention of thermal bridging is a critical issue.

Under the national program of revitalization of FRAC (Fonds Régional d'Art Contemporain), the Central Region, in the heart of Orleans, opened a modern building with innovative architecture in September 2013. With the aim to better meet the needs of contemporary art lovers while promoting the historic military supply depot.The architect firm, Jakob + MacFarlane, wished to capitalize on a strong aesthetic in the heart of the urban environment. Built in the old building Subsistances Military, the structure is based on a geometric distortion by the emergence of a dynamic set of three volumes of glass. These three "Turbulence" are wrapped in a metal mesh on the outside and fabric inside. The project architect's intention for FRAC Centre is to create a place of constant change through a "live" and interactive architecture that combines image, light and information. A system of diodes positioned on Turbulence will highlight program FRAC through an animated game designed by Electronic Shadow artists.To ensure complete isolation of the building, the complex architecture and its metal frame, the thermal breaks, Schöck Isokorb® T type S were integrated to treat energy loss at the connection of the frame with the outer skin. Schöck Isokorb® T type S is a steel to steel thermal break connection that takes the bending moment and shear force in cantilevered metal structures.Read more about The Les Turbulences FRAC Centre, featured in Architectural Record.

Some of Europe's most sophisticated buildings incorporate thermal break technology from Schöck, but the new Mercury City Tower in Moscow is to date possibly the most iconic, and certainly the tallest, to utilise the Isokorb®.Rising 327 metres above the Moscow skyline, the Mercury City Tower, is currently the highest building in Europe, beating London's Shard into second place by some 17 metres. This remarkable building is the centrepiece of a £7 billion International Business Centre development known as Moscow City, located about two and a half miles to the west of Red Square.It is bult on a 150 acre site that used to be an old stone quarry area consisting of derelict factories and industrial complexes and will shortly become the first zone in Russia to combine business activity, living space and entertainment in one single development. Claimed to be the first truly environmentally-friendly building in Russia, it will house the offices of some of the world's leading companies; along with five-star hotels, luxury apartments, prestigious clubs, fitness centres, fashion boutiques – and even Moscow's largest concert hall will be relocated there – making it effectively a city within a city.A key design feature of the building is the use of inclined planes at various levels of the structure, which support vertical posts on which the facade cleaning system is installed. To prevent any of the risks associated with thermal bridging, it is necessary to separate the vertical posts from the thermal contour of the building. The unusual shape, size and characteristics of Mercury City required careful planning and the design of a unique Isokorb® T insulation element; which in addition to its exceptional thermal performance requirements, also has to bear loads on two of the inclined planes.

Preventing punching shear failure with flat slab construction is critical and while traditional solutions such as links in the punching area work fairly effectively, there are disadvantages. They are time-consuming to install and risk installation inaccuracy and positional stability during concreting. A product that does offer a cost-effective, easy-to-install solution, is the widely used and dependable Schöck Bole shear rail; and one of the many construction sites where Bole is the system of choice is the New Green project at Rainham in Essex, where two outdated 13-storey tower blocks are being replaced by mid-rise, high density buildings, providing 197 homes. As with any reinforced concrete slab design, the New Green project is at risk of punching shear failure, which traditionally has been resolved by adding further concrete, such as the use of downstand beams or localised thickened column heads. However these measures require complex formwork and significantly reduce the benefits offered by the flat slab design. By incorporating the Schöck Bole shear rail system, installation is cost-effective and significantly faster than traditional loose links. The ready-to-install reinforcement element consists of double-headed studs with spacing bars to ensure correct positioning.  Spacers allow installation on the formwork, making installation on the construction site and in the precast plant quicker, safer and easier to achieve. The dramatically reduced fixing time far outweighs any additional material costs that may be involved with a prefabricated system.

Sitting adjacent to Manchester Victoria station, the £185m New Victoria development is a two-phase scheme initially involving two residential towers of 20 and 25 storeys providing 520 one, two and three bed apartments. The second phase being a 13-storey office block. The façade concept is a ‘hooped envelope around a glass box’ with the ‘envelope’ consisting of vertical panels from the first floor to roof level. As with any reinforced concrete slab design, the project is at risk of punching shear failure. Which traditionally has been resolved by adding further concrete, such as downstand beams or localised thickened column heads. However these measures require complex formwork and significantly reduce the benefits of the flat slab design. By incorporating the Schöck Bole shear rail system – with its ready-to-install reinforcement element consisting of double-headed studs with spacing bars to ensure correct positioning – installation is cost-effective and significantly faster than traditional loose links. In fact, Shaun Farrell of Mayo Civils, the concrete frame contractor, comments: “We were pleased to find that by using the Bole shear rail system on the project, installation was four times faster than if we had used shear links.” Shaun goes on to explain that: “when using traditional links the installation time is increased because twelve ties are involved, six of which have to be tied to the bottom steel matt, which involves getting your hands between the rebar. With the Schöck Bole six-stud shear rail, it only involves two ties to the top matt”.

The Olympic Village consists of 11 blocks, each block comprising between six and eight individual buildings, which are eight to twelve storeys high. Of the many amenities in the Village, by far the largest usage is for apartments, of which there are around 3000 units.Despite the height and density of the scheme, it has a surprisingly open feel, aided by the glazed winter gardens and mostly generous sized balconies, which are very much in evidence throughout the entire development. There was a huge demand here for the Schöck Isokorb®, with around 10,000 thermally broken structural connections to be considered. For podium slabs and pre-cast balcony applications the Isokorb® T type K, for concrete-to-concrete connectivity was used. The T type S, T type Q-P and Schöck SLD dowels combined to meet the requirement for securing the winter garden balconies. Types SK-MM1 and SK-MM2 for steel-to-concrete, provided the solution for connecting the various concrete frames to steel balconies.Some of the steel balconies had a cantilever length of approximately two metres and in most cases SK-MM2 units offered the ideal solution. However, in certain locations – concrete edge beams for example – the reinforcement bars had to be shaped to suit and for these applications special SK-MM1 modules were utilised.The unusual T-shaped winter gardens provided one of the greater challenges. Remarkably, the winter garden concrete slabs are designed to span two building blocks – approximately seven metres – and it was essential to allow for movement of the slabs by combining the Isokorb® T type Q-P at one end and SLD dowels at the other.Exceptionally strong steel-to-concrete thermal break connections were required and usually the Isokorb® T type SK would be the natural choice. On this occasion however, the forces involved exceeded even the capabilities of the SK units and it was necessary to design a T type S configuration, in combination with a specially developed steel bracket. Back at ground and first floor levels a huge number of T type K concrete-to-concrete thermal breaks were required for the large slab sections. In some cases the extreme dimensions of the slab sections resulted in thermal movement beyond the Isokorb®'s capability and SLD dowels were used in their place.

The Rathbone Market scheme, part of the Canning Town and Custom House regeneration programme, is a three-phase development that when complete will see the area totally reinvigorated. There will be a new market square at the heart of the community, bordered by around 35,000 sq ft of new shops and cafes. The development will also feature offices; community facilities, two new public squares and 652 new homes.The majority of apartments on the upper levels will have a double aspect and all will have balconies. The intention is to provide a development of great visual depth, using two colours of brick. The balconies are designed with an unusually large 2.3 metre cantilever and to meet this demanding specification, it is the Schöck Isokorb® that is being incorporated into the project. Specifically the product being used at Rathbone Market is the Schöck Isokorb® T type SK for concrete-to-steel connectivity. It is 180mm wide and between 180 and 280mm high to allow flexible adjustment for differing slab thicknesses and contains 80mm of insulation thickness. It can also bear extremely heavy loads and this combination of features makes the units ideal in meeting the various thermal and structural demands involved with such large modern balconies.

Schöck in the "Green Center". New Residential Complex in Linz.In the Upper Austrian capital city Linz, a new urban district known as the "Green Center” is being created. It will provide about 800 apartments. In this context, the Schöck Isokorb® T is a substantial component.Seven non-profit real estate developers are building a new heart for the city on an area of 87,000 m² in its geographical center – the largest urban development project in Linz for decades. As of 2016, a total of 800 apartments will have been erected and in accordance with the socio-demographic development, 50 assisted living housing units and a kindergarten – all on the site of the former freight railway station.In this complex we wanted to create "a sea of green, stretching from private gardens, terraces, loggias and balconies up to the roof tops, " explained the city officials. This is also where its name comes from.14,000 m² of parklandAll objects are being built with net zero-energy efficient features. Solar collectors are being installed on many roofs to provide hot water. As part of the thermal insulation, Schöck’s Isokorb® T thermally separates elements while forming part of the structure. It is being used here on a massive scale in different variants. Around 1,700 units were installed in five different building complexes. The versatile range of Schöck Isokorb® T structural thermal breaks allowed the planners great scope for design and energy efficient solutions, since they not only offer thermal separation and additional fire protection but also freedom of interface access (e.g. balcony to living space). In addition to Isokorb® T, Schöck Dorn (shear reinforcement, heavy-duty dowel), Schöck Bole® (punching shear reinforcement) and the Sound Protection System Schöck Tronsole® (for stairwells) were used in many installations.A total of 89 apartments with 75 balconies will be built whereby the ground floor apartments each have their own small garden. The roof surfaces are all planted. The living areas of balconies that extend outwards have an L-profile. The resulting visual plant staircase on the sunny facades creates the impression of a hanging garden for the residents and neighbors. This has a relatively striking effect and yet this version of gradation and the enclosed balustrades provides a certain degree of privacy for the inhabitants. To achieve the desired level of green, balconies are to have two flower boxes each (1.5m in length) that will be tended to by the residents. The three-meter deep balconies are thermally separated with Schöck Isokorb® T elements.Arcades thermally separated"We have done everything that is technically expedient to save energy. The Isokorb® T has been installed in the terraces and arcades" (Karrer). A solar system was installed on the roof. "All the green diminishes the specified high construction density," says the architect. Gradated terraces ensure that even in the courtyards there’s good light. The buildings were handed over in the summer of 2014.

The “Wohnpark in der südlichen Luisenstrasse” residential project was built in Karlsruhe in 2015. At the client’s request, architects AGP Generalplaner GmbH designed the building with enhanced impact sound insulation. Schöck Tronsole® was chosen as the impact sound insulation system for the stairs.Spacious rental and owner-occupied apartments with 1, 2 and 3 bedrooms were designed on a floor area totalling 18,000 m². All of the stairs in the buildings comply with the requirements of soundproofing level III as per VDI 4100 or DEGA class B. Specifically, the measured standard impact sound level of the stairs and landings ranges between 32 dB and 38 dB. These levels are about 10 dB better than the required standard impact sound level of 46 dB. By comparison: A reduction of 10 dB is equivalent to reducing the volume by half. The residents in the complex in Karlsruhe will notice this difference quite clearly. By not being able to impact noise from the stairs. The stairs are soundproofed using Schöck Tronsole® type F on the ceiling slabs while Tronsole® type Z separates the landings from the stairs and outer walls. The supporting element for the Tronsole® type Z was cemented into the 26 cm landing back at the prefabricating plant. Accordingly, the Tronsole® type Z wall element was installed and type F fastened to the landings and stairs on site.

Riverwalk features two organically shaped buildings of 7 and 17 storeys, connected by a central podium and incorporating 116 high specification one, two, three and four bedroom apartments, plus penthouses. The design focus is on light, space and service, as well as exceptional views across the River Thames. Extensive planting on roofs, balconies and terraces, most significantly on the first floor podium terrace, also contribute to a substantial improvement in the green footprint and biodiversity of the site.With such a high specification development it is not surprising to find that enormous consideration was given to the avoidance of the thermal bridging at the critical balcony connections; and the structural thermal break module specified throughout is the latest generation Schöck Isokorb® XT type K. The XT type K – for concrete-to-concrete applications – offers such a high level of insulation that the Passivhaus Institute in Darmstadt has awarded the product with the "low thermal bridge construction" certificate and confirmed its suitability even for passivhaus construction.A major reason for the superior performance of the Schöck Isokorb® XT type K is the thickness of the insulation body. This is increased from the standard 80mm thick to 120mm, providing an even more efficient solution. The Isokorb® XT type K not only improves thermal insulation performance by up to 30% in comparison to to the standard range, it also improves impact sound insulation by around 50% as well. High quality stainless steel bars with improved tensile strength is an integral part of the unit and while the same load-bearing capacity is maintained, there is a smaller rod diameter and therefore a reduction in the thermally conducting cross-section, resulting in a further increase in the heat insulation performance.

Tim Paul from Rick Mather comments: 'Balconies offer practical and aesthetic advantages for residents, but they have not always been a popular choice in the context of high efficiency Passivhaus design. However, the advanced technology and superior performance of the Schöck Isokorb® XT range offers such a high level of insulation, that we had no problem in incorporating balcony design into the Chester Balmore project'

It is anticipated that when completed in the next ten years or so, the regeneration of Wembley Park, in North West London, will provide up to 7000 new homes. Schöck is supplying its Isokorb structural thermal break systems across a number of different sites on this vast scheme, but one of the largest is South West Lands. This private rented sector residential-led mixed-use neighbourhood will account for around 12% of the new homes on the entire Wembley Park development, up to 900 in total.South West Lands is spread across four separate blocks, which all share a communal basement car park.The reinforced concrete frame buildings, up to 18 storeys high, are finished using traditional brickwork and standing seam metal cladding. To create valuable amenity space at higher levels, as well as offering far-reaching views across London, there are communal roof terraces and a considerable number of private balconies throughout the development.Schöck Isokorb® T type SK products were used on two of the phases at South West Lands for thermally connecting the cantilevered steel balconies to the reinforced concrete slab. The Isokorb® T type SK units were positioned accurately using re-useable balcony width steel jigs.

The Beckett, a new retirement village close to the centre of Royal Tunbridge Wells, in Kent, comprises three luxury apartment buildings of three, four and six storeys. The contemporary design provides 89 quality appointed apartments with a landscaped garden, all arranged around full-height atriums, allowing natural light to reach the centre of the buildings. The upper floors are set back, providing generous terrace areas which include a ‘sky lounge‘. All three buildings are concrete frame and as with any reinforced concrete slab design, The Beckett is at risk of punching shear failure, which traditionally has been resolved by adding further concrete, such as downstand beams, or localised thickened column heads. However these require complex formwork and significantly reduce the benefits offered by the flat slab design. The Schöck Bole shear rail system counters any punching shear risk and is cost-effective and significantly faster than traditional loose links – as much as four times faster in fact. This is because when using traditional links it involves far more ties to the reinforcement matt than when using the Schöck Bole. The ready-to-install reinforcement element consists of double-headed studs with spacing bars to ensure correct positioning. Two spacer bars are welded to the vertical studs, which ensure the correct distance between uprights and the forged stud heads guarantee a perfect finishing bond with the concrete. The dramatically reduced fixing time far outweighs any additional material costs that may be involved with a prefabricated system.

The 'HOOLA' in Tidal Basin Road in East London, gateway to the soon-to-be regenerated Royal Victoria Docks area, has transformed a brownfield site into two rippling 23 and 24 storey glass towers, that offer 360 apartments with a mix of studios, along with one, two and three-bedroom units.The buildings are super-insulated and the concrete frame will act as a heat sink – absorbing heat on warm days and releasing it back into apartments when it cools. An innovative link-up with the neighbouring ExCel Exhibition Centre will also see excess heat piped directly into the two towers. This will provide all the necessary heating and hot water requirements and significantly reduce maintenance costs by doing away with the need for individual boilers. A critical design requirement for such a super-insulated building was the avoidance of any risk of thermal bridging at the many concrete-to-concrete balcony connectivity points – so highly efficient structural thermal breaks were required throughout. The preferred solution was the Schöck Isokorb® T type K for cantilever balconies.Luke Smerdon-White, Technical Director at Thorp, takes up the story: "We had to design, manufacture and deliver 1410 precast concrete balcony sections that had to then be cast integrally with the in situ concrete structure." "The exposed front-face is curved, with almost 50 different dimensional configurations, while the internal face has a facetted line that had to correlate with the glazing line and opening doors."

The iconic architecture of the three Kranhäuser buildings in Cologne’s former commercial harbour is reminiscent of the old loading cranes that could once be found here. While the two initial structures were designed as office spaces, the last in the collection – Kranhaus Nord – is entirely residential. This means there were high standards to meet with regard to impact sound insulation in this construction. Fortunately, Schöck Tronsole® type T offered the perfect system solution in this regard.Both the structural engineering and architectural planning processes for this residence had to be adapted accordingly to suit the high-end use of the building. Unlike the design of the office buildings, the bridge abutments are connected via an atrium that leads to the premium apartments rather than being separated.The main stairwell runs right alongside premium apartments, which means sound proofing was a key consideration. This was required not only due to standard building regulations, but also for the fact that “as a provider of luxury apartments complete with a whole host of amenities for international clients, people expect top quality. Thus, the decision was made to use the Schöck Tronsole® sound proofing system: A tried-and-tested solution for integration into stairwells.”
