Application

  • Roofs between 15-70 degrees pitch where 10mm /10,000 mm² per metre ventilation is required.
  • Suitable for use with replacement fascia boards and capping of all sizes.

Description

Felt support trays are used to stop the felt from draping into the gutter, and to prevent water ponding behind the facias which can rot the felt. The over fascia vent encourages natural airflow through the roof space.


Features and Benefits:

  • Easy to install interlocking trays.
  • Cost-effective.
  • Saves time by fitting tray & vent simultaneously.
  • Pre-drilled nail/ screw ports for faster installation.
  • UV Stable & Durable.
  • Made From 100% re-processed material in the UK.
  • 15-year guarantee.


Quality Standards:

  • Satisfies all NHBC requirements.
  • Conforms to BS 5250:   For Roof Space Ventilation (Management and Moisture in Buildings).


General information

Color

Black

Material

Polypropylene

Shape

Rectangle

Length

1000 mm

Width

200 mm

Height

55 mm

Warranty description

15 year

Uniclass

Pr_30_59_29_62 Plastics eaves underlay supportPrimary

CAWS

H62/355 Ventilated eaves with separated grilles/ trays

H61/355 Ventilated eaves with separated grilles/ rays

H60/355 Ventilated eaves with separated grilles/ trays

H65/355 Ventilated eaves – separated grilles/ trays

Product range

Eaves Level Ventilation

Specification data - Plastics eaves underlay support

Style

2-in-1 felt support tray.

Colour

Black.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

100 %

Literature

2-in-1 Felt Support Tray Datasheet

2-in-1 Felt Support Tray Datasheet
