Name: Anthracite Cubicles | Toilet & Shower - Compact Cubicles
Brand: Bristol Panel Formers
SKU: aCusR2RVvaGbnpet6LFPKJ

Color

Beige

Black

Blue

Cream

Green

Finish

Smooth

Woodgrain

Satin

Eggshell

Material

Solid grade laminate (SGL)

Shape

Rectangle

Square

Other

Length

1500 mm

Guidance for specification option:

Standard depth.

Bespoke

Width

Bespoke

Height

1950 mm

Guidance for specification option:

Overall (panel/ door/ pilaster height: 1800 mm; floor clearance: 150 mm).

Uniclass

Ss_25_12_60_60 Panel cubicle systemsPrimary

CAWS

K32/120 Panel cubicles

K32/10 Panel cubicles

Classification data

System performance

Guidance for specification option:

Insert requirements.

Panels

12 mm-thick solid grade laminate (SGL).

Guidance for specification option:

Includes ‘U’ brackets for through-bolting partitions and pilasters.

Panel supports

150 mm-high aluminium cubicle legs with height adjustment.

Manufacturer guidance

100 and 50 mm-high aluminium legs also available, consult manufacturer for details. Note this affects the overall height.

Pilasters

12 mm-thick solid grade laminate (SGL).

Doors

12 mm-thick solid grade laminate (SGL).

Lippings

Polished and radiused on all edges leaving a smooth black edge.

Hardware

Indicator bolt; hinges; hat and coat hook; U-brackets; headrail.
Polyester powder-coated (PPC), charcoal grey colour (RAL 7024).

Manufacturer guidance

Satin anodized aluminium (SAA) or satin stainless steel (SSS) fittings also available, consult manufacturer for details. Note that the standard anthracite fittings give the system its name.

System accessories

None.

Toilet roll holder.

Colour/ Finish

Genêt (G031).

Guidance for specification option:

FA finish.

Vinyle (V014).

Guidance for specification option:

FA finish.

Capucine (C062).

Guidance for specification option:

FA finish.

Rouge Cerise (R036).

Guidance for specification option:

FA finish.

Rouge Amarante (R057).

Guidance for specification option:

FA finish.

Zeste de Citron (Z016).

Guidance for specification option:

FA finish.

Pomme Verte (P092).

Guidance for specification option:

FA finish.

Cactus (C049).

Guidance for specification option:

FA finish.

Vert Bali (V109).

Guidance for specification option:

FA finish.

Vert Impérial (V110).

Guidance for specification option:

FA finish.

Bleu Flash (B001).

Guidance for specification option:

FA finish.

Mousse (M047).

Guidance for specification option:

FA finish.

Nova Mousse (N028 ).

Guidance for specification option:

SURF - FA finish.

Bleu Turquoise (B119).

Guidance for specification option:

FA finish.

Bleu Buée (B194).

Guidance for specification option:

FA finish.

Bleu Caraïbes (B086).

Guidance for specification option:

FA finish.

Nova Saphir (N023q ).

Guidance for specification option:

SURF - FA finish.

Chardon (C018).

Guidance for specification option:

FA finish.

Zeste Indigo (Z038).

Guidance for specification option:

FA finish.

Bleu Oslo (B048).

Guidance for specification option:

FA finish.

Cyclamen (C189).

Guidance for specification option:

FA finish.

Rose Indien (R059).

Guidance for specification option:

FA finish.

Coquille d’OEuf (C017).

Guidance for specification option:

FA finish.

Beige Nature (B116).

Guidance for specification option:

FA finish.

Pierre de Lune (P001).

Guidance for specification option:

FA finish.

Gris Tourterelle (G029).

Guidance for specification option:

FA finish.

Zeste Coco (Z022).

Guidance for specification option:

FA finish.

Blanc Megève (B070).

Guidance for specification option:

FA finish.

Blanc Menuires (B015).

Guidance for specification option:

FA finish.

Orgeat (O111).

Guidance for specification option:

FA finish.

Gris Perle (G003).

Guidance for specification option:

FA finish.

Gris Cendré (G075).

Guidance for specification option:

FA finish.

Gris Orage (G059).

Guidance for specification option:

FA finish.

Caviar (C011 ).

Guidance for specification option:

SURF - FA finish.

Noir (N005).

Guidance for specification option:

FA finish.

Chêne Colorado (C149).

Guidance for specification option:

Natural finishes range.

FA finish.

Noisetier Naturel (N056).

Guidance for specification option:

Natural finishes range.

FA finish.

Chêne Clair Horizontal (C102).

Guidance for specification option:

Natural finishes range.

FA finish.

Chêne Alba (C180).

Guidance for specification option:

Natural finishes range.

FA finish.

Érable Féroé Horizontal (E104).

Guidance for specification option:

Natural finishes range.

FA finish.

Noyer Havana Horizontal (N115).

Guidance for specification option:

Natural finishes range.

FA finish.

Noyer Ombré (N026).

Guidance for specification option:

Natural finishes range.

FA finish.

Chêne Brun Horizontal (C101).

Guidance for specification option:

Natural finishes range.

FA finish.

Banian Blanchi (B100).

Guidance for specification option:

Natural finishes range.

FA finish.

Chêne d’Argent (C183).

Guidance for specification option:

Natural finishes range.

FA finish.

Banian Noirci (B101).

Guidance for specification option:

Natural finishes range.

FA finish.

Teck Carbone (T105).

Guidance for specification option:

Natural finishes range.

FA finish.

Marbre Taisa (M124).

Guidance for specification option:

Natural finishes range.

FA finish.

Travertin Naturel (T108).

Guidance for specification option:

Natural finishes range.

FA finish.

Marbre Siroco (M134).

Guidance for specification option:

Natural finishes range.

FA finish.

Maryland Clair (M001).

Guidance for specification option:

Natural finishes range.

SURF - FA finish.

Maryland Foncé (M003).

Guidance for specification option:

Natural finishes range.

SURF - FA finish.

Configuration

Between walls.

Corner type.

Inline.

Corner type inline.

Freestanding.

Other.

Dimensions

Guidance for specification option:

Insert requirements or refer to drawing/ schedule as required.

Manufacturer guidance

Height (overall): 1950 mm (panel: 1800 mm; floor clearance: 150 mm).
Panel depth: 1500 mm as standard or as specified.
