Artemis+ - Standard Height Cubicle - Panel Cubicle

Name: Artemis+ - Standard Height Cubicle - Panel Cubicle
Brand: Brookhouse
SKU: tx11X2D2YenjxgsCNpABrW

Verified by manufacturer 6 months ago

MFC

Brookhouse

A standard height cubicle system for high-traffic washrooms.

Jump to:

+44 (0)345 383 0050 Website

Application

Cubicle solution for:

Education.
Further education.
Higher education.
Transport.
Commercial.
Public environments.
Sports and leisure facilities.
Healthcare.

Description

Artemis+ is a standard height cubicle solution for high-traffic washrooms. Brookhouse washroom cubicles are available in a range of colours and finishes.

Artemis+ is offered in three material choices:

MFC for low-risk vandalism environments in dry settings.
HPL for washrooms with higher usage. These panels offer heat, scratch and impact resistance.
SGL Solid-grade laminate exhibits exceptional resistance to impact and its surfaces are impermeable to water.

Features and benefits:

Made to measure.
Cost-effective.
Hygienic, easy to clean and antibacterial.
Longevity.
Durable construction.

General information

Color	White Cream Black Grey Yellow Purple Red Pink Green Blue Brown Show more
Finish	Smooth Wood grain
Material	MFC High pressure laminate (HPL) Solid grade laminate (SGL)
Length	Bespoke Guidance for specification option: Maximum depth: MFC 1500 mm; HPL 1500 mm; SGL 1820 mm.
Width	Bespoke
Height	Bespoke 2400 mm Guidance for specification option: Maximum height: 2400 mm. Manufacturer guidance Floor clearance: 150 mm.
Warranty description	Ten year

Uniclass	Ss_25_12_60_60 Panel cubicle systemsPrimary
CAWS	K32/120 Panel cubicles K32/10 Panel cubicles

Product range	Brookhouse \| Washroom Cubicles

Specification data - Panel cubicle systems

Classification data
Panels	19 mm Melamine faced chipboard (MFC) boards.
Panel supports	Satin anodized aluminium adjustable pedestal.
Pilasters	19 mm Melamine faced chipboard (MFC) boards.
Doors	19 mm Melamine faced chipboard (MFC) boards.
Lippings	ABS.
Hardware	Hinges: Clasp bracket with self-closing cams. Indicator bolt: Slide action lock with integrated indicator and emergency door release facility.
System accessories	Not required. Powder-coated hardware. Coat hook, 1no. per cubicle.
Headrail	P headrail.
Colour/ Finish	0606 FH Arctic White. 0085 FH White. 0733 FH Hygienic White. 0851 FH Winter White. 0080 FH Black. 0762 FH Neutral Medium Grey. 0007 Dark Grey. 0008 Warm Dark Grey. 0077 FH Charcoal. 0010 FHMango. 2274 FH Lilas Rouge. 0210 FH Intensive Red. 0020 FH Ballerina. 0725 FH Yellowish Green. 0024 FH Vivo 0041 FH Tortuga. 0630 FH Sea Green. 0718 FH Arctic. 0717 FH Atlantic. 0237 FH Gentian Blue. 0023 FH Lamar. 0558 FH White Punto. 0559 FH Punto Pastel Grey. 0328 FH Brushed Aluminium. 0551 FH Whitney. 0419 FH Pinero. 0252 FH Madera. 0538 FH Charles. 0260 FH Arezzo. 0607 FH Loen. 0026 FH Prado Alu Grey. 0027 FH Prado Agate Grey.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Manufacturing plant location	unit 2, 7 Sheepcotes, Springfield, Chelmsford CM2 5AS, UK
Material	MFC High pressure laminate (HPL) Solid grade laminate (SGL)
A1-A3 (production stage)	Embodied carbon as defined in BS EN 15804
Normalised unit
Declared unit	20.9 kg CO₂ eq/unit Self-declared Manufacturer guidance of the SGL Panels
Recyclability	100% Manufacturer guidance of the SGL Panels
Recycled content As defined in clause 7.8 of BS EN ISO 14021	100 % Manufacturer guidance of the SGL Panels
Expected Life	Ten year
