Aspire Cubicles - Unframed Panel Cubicle
Verified by manufacturer 1 day ago
Aspire - MR MFC
Aspire - MR MFC
Unframed, custom-fit panel cubicles.
Application
For those projects on a tighter deadline, the Aspire range uses our range of RapidFit colours to create made to measure cubicles that don’t need to be altered on site. When quality, budget and lead time matter more than colour options, the Aspire range will deliver every time.
Description
Unframed, custom-fit panel cubicles available in moisture-resistant melamine faced chipboard (MR MFC) or solid grade laminate (SGL).
Features and benefits:
- 3 Week lead time from drawing approval.
- Made to measure - helps to create a bespoke washroom.
- Simplified colour choice.
- High quality.
- Doors are fitted with lift-off emergency hinges as well as an emergency release lock.
- Robust, powder-coated nickel ironmongery ensures durability.
- Panels do not need to be altered on site (scribing may be required).
General information
Color | White Blue Grey Brown Turquoise Manufacturer guidanceSee the Colour Selector brochure for swatches. |
Finish | Laminated Other |
Material | MFC Solid grade laminate (SGL) Aluminium Acrylonitrile butadiene styrene (ABS) |
Length | 1525 mm Bespoke Manufacturer guidanceDepth. |
Width | Bespoke |
Height | 1950 mm |
Warranty description | Five year Guidance for specification option: MR MFC. Ten year Guidance for specification option: SGL. |
Uniclass | |
CAWS | K32/120 Panel cubicles K32/10 Panel cubicles |
Specification data - Panel cubicle systems
Classification data | |
Panels | 600 kg/m³ moisture-resistant melamine faced chipboard (MR MFC), 19 mm. |
Panel supports | Aluminium, nickel painted polyester powder-coated (PPC) pedestal. Guidance for specification option: Pedestal adjustment: +/- 20 mm. |
Pilasters | 600 kg/m³ moisture-resistant melamine faced chipboard (MR MFC), 19 mm. |
Doors | 600 kg/m³ moisture-resistant melamine faced chipboard (MR MFC), 19 mm. |
Lippings | 2 mm matching acrylonitrile butadiene styrene (ABS). |
Hardware | Aluminium, nickel painted polyester powder-coated (PPC) lift-off gravity hinges with front caps. Indicator bolt and keeper. Guidance for specification option: Indicator bolt: Aluminium slide action lock with no visible fixings. Circular flush fitting faceplate and emergency release facility. |
System accessories | Manufacturer guidanceConsult manufacturer and insert requirements or omit. |
Dimensions | Finished floor level: 1950 mm. Panel height: 1800 mm. Partition depth: As standard 1525 mm (1500 mm deep partition panels). Maximum 1840 mm. Door size: Consult manufacturer for details. Manufacturer guidanceConsult manufacturer for further details. |
Headrail | Aluminium, nickel painted polyester powder-coated (PPC) slimline ‘U’ channel with no visible fixings. |
Floor Clearance | 150 mm. |
Finish | Royal white U11209. Water blue U18002. Texwood grey F73048. Slate grey U12231. Sangha wenge R50004. Light grey U12188. Lagoon U18505. Grey sonoma oak R20039. Be rooted U16058. Manufacturer guidanceSee the Colour Selector brochure for swatches. |
Fixings | Aluminium, nickel painted polyester powder-coated (PPC) ‘U’ brackets with bolt through fixings. Manufacturer guidanceWall fixings. |
Size | Manufacturer's standard. Guidance for specification option: Pilaster sizes are designed and proposed based on site sizes or layout drawings. Consult manufacturer for details. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | United Kingdom |
Manufacturing plant location | |
Material | MFC Solid grade laminate (SGL) Aluminium Acrylonitrile butadiene styrene (ABS) |
Recyclability | MR MFC can be recycled into chipboard or as bio-mass. SGL can only be used as bio-mass. Aluminium Ironmongery can be recycled repeatedly without losing it's quality. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 85 % |
Expected Life | Five year Ten year |
