Braemar Constellation | Concrete Block Paving
Verified by manufacturer 3 months ago
Indus
Indus
Signature Mixes
Application
Can be installed externally and internally.
Description
Braemar is widely recognised as the premium concrete alternative to natural granite. It is manufactured with natural aggregates that emulate the distinct aesthetics of natural stone. As a premium product, Braemar will add real value to projects in terms of fulfilling aesthetic and design aspirations and exceeding technical requirements. The possibilities for landscape designers are truly endless with various colour blends available.
Features and benefits:
- Manufactured with natural granite aggregates.
- Low slip/ skid risk.
- Hard-wearing granite surface.
- Long-lasting colours.
- Ground finish created using a diamond grinding process.
- Manufactured in accordance with ISO 9001:2008 Quality System, ISO 14001:2004 Environmental Management and BES 6001 Responsible Sourcing.
- 100% renewable energy used.
- 100% water used from rainwater harvesting system.
- BREEAM rating A.
General information
Color | Black Guidance for specification option: Corvus. |
Finish | Textured Guidance for specification option: Ground or Ground Textured. |
Material | Concrete |
Shape | Rectangle |
Length | 200 mm 300 mm 600 mm |
Width | 100 mm 200 mm 300 mm |
Height | 80 mm |
Uniclass | |
CAWS | Q24/10 Conventional concrete block paving Q24/110 Conventional concrete block paving |
Specification data - Concrete paving blocks
Standard | To BS EN 1338. |
Physical properties | |
Finish | Ground.Ground textured.Guidance for specification option: Higher level of slip resistance. |
Profile | |
Paver type | Regular plan form. |
Dimensions and associated tolerances | |
Nominal sizes | 200 x 100 x 80 mm.300 x 200 x 80 mm.600 x 300 x 80 mm. |
Strength | ˃3.6 MPa. Guidance for specification option: To BS EN 1338: 2003. ˃5 MPa Class 3. Guidance for specification option: To BS EN 1339: 2003. |
SurfaceLayer | 4 mm and >390 kg/m³ cement. |
Efflorescence | Minimum 12 hour vapour curing. |
BREEAM rating | A. |
Sustainability data
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | Manufacturer guidance50.74kgCo2 e/m2 (+7%, – 0.6% depending on specific product) |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | Manufacturer guidance
|
Literature
Braemar slabs and block paving - Premium concrete alternative to natural stone
