Canadian Western Red Cedar Timber Cladding

Name: Canadian Western Red Cedar Timber Cladding
Brand: NORclad Limited
SKU: eFyQeUYBfoJ1gGwybkBWmd

Verified by manufacturer 14 days ago

NWC1

NORclad Limited

Naturally durable species of timber cladding

Jump to:

+44 (0)1275 794735 Website

Application

Typically used for timber cladding, brise soleil, solar shading, shingles and decking.

Description

Canadian Western Red Cedar is a slow-grown, naturally durable species of timber with high resistance to decay.
It is stable and lightweight, with a natural beauty and warmth complemented by a uniform fine grain which makes it easy to work with and finish.
It is a soft timber and can be nailed or screwed. However, as it is a soft timber it may be more prone to physical damage such as splitting and indentation/ bruising, so care should be taken.
Most Western Red Cedar used in the UK is imported from North America and Western Canada.
Cedar will naturally weather down to a silver/ grey colour if it is not protected once installed.
The species is durable and does not need additional treatment for external use.
For an element of colour stability the product can be high pressure treated with the "Brunnea" option, containing a brown pigment.
NORclad Brunnea and NORclad Lite provide a 30-year warranty against rot and fungal decay.

General information

Color	Brown Grey Pink Manufacturer guidance Salmon pink sapwood to dark brown heartwood, if left unprotected, it will turn to a silver/ grey colour. Many boards supplied are clear boards.
Material	Wood
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Guidance for specification option: NORclad Brunea and NORclad Lite offers a 30-year warranty against rot and fungal decay.

Uniclass	Pr_25_71_97_84 Softwood weatherboardsPrimary
CAWS	H21/10 Vertical timber weatherboarding H21/110 Vertical timber weatherboarding H21/111 Horizontal timber weatherboarding H21/115 Vertical timber weatherboarding H21/15 Horizontal timber weatherboarding

Specification data - Softwood weatherboards

Standard	All timber is sourced and machined to CE Quality Grading Requirements.
Resistance to fixings	Manufacturer's standard. Guidance for specification option: It is a soft timber and can be nailed or screwed. As it is a soft timber it may be more prone to physical damage such as splitting and indentation/ bruising, care should be taken.
Wood species	Canadian western red cedar. Guidance for specification option: Softwood. Manufacturer guidance All from well managed forests - PEFC, FSC and or CSC certified. Origin: Canadian – North America and Western Canada.
Quality of timber (exposed surfaces)	Canadian WRC 2 Clear & Better. Guidance for specification option: Maximum live knot diameter on face: 19 mm, limited along the length of timber. Canadian WRC 2 Clear & Better 15% 4 Clear. Guidance for specification option: Maximum live knot diameter on face: 38 mm, limited along the length of timber. Including a percentage of boards graded to No. 4 Clear, the majority meeting No. 2 Clear. Manufacturer guidance To EN 14915. NORclad Timber Cladding is produced in accordance with factory production control for selection, grading, machining and preservative treatment of solid wood cladding. PEFC certified, sustainably sourced Timber. Imported from Canada. All timber is sourced and machined to CE quality Grading Requirements. Many boards supplied are clear boards.
Profile	Tongued and grooved, face fix.
Finished size	-
Face width	Manufacturer's standard. Guidance for specification option: Overall width: 150 mm.
Thickness	22 mm.
Biological durability	-
Preservative treatment	Not required. NORclad Brunnea™. Guidance for specification option: Provides a 30 year warranty against rot and fungal decay. The treatment process enables the timber to hold colour longer, requiring little or no maintenance. NORclad Lite™. Guidance for specification option: Offers a 30 year warranty against rot and fungal decay. This treatment does not contain a pigment and therefore upon exposure to UV light the colour will enrich before beginning to naturally weather to a silver/ grey over time.
Execution	- Manufacturer guidance Only top-quality stainless steel fixings should be used to avoid corrosion of fixings and blue staining of the profile.

Corner trims	Not required. NWA1. Guidance for specification option: 75 x 75 mm. External corner trim, flush. NWA2. Guidance for specification option: 50 x 50 mm. Internal corner trim, Scotia. NWA3. Guidance for specification option: 63 x 63 mm. External corner trim L-profile. NWA4. Guidance for specification option: 50 x 50 mm. Internal corner trim, square.
Density	390 kg/m³. Guidance for specification option: At 16% moisture content.
Dimensional stability	Small. Manufacturer guidance It has a very low shrinkage factor and is superior to all other coniferous woods in its resistance to warping, twisting and checking.
Fixings	Stainless steel fixings are always recommended.
Properties	Manufacturer's standard. Guidance for specification option: Chemical properties: This specie has natural preservatives which can have a corrosive effect on some unprotected metals, causing a black stain on the wood.
Sustainability requirements	Sourced from well managed forests – FSC certified available on request.
