CFS-W Firestop Wrap

Verified by manufacturer 1 month ago

CFS-W EL Firestop Endless Wrap

Hilti (Gt Britain) Ltd Variant:
Third party certifications:
  • European Technical Approval (ETA)

    European Technical Approval (ETA)

    Certificate type

  • UK Technical Assessment (UKTA)

    UK Technical Assessment (UKTA)

    Certificate type

Firestop wrap strip.

Jump to:
+44 (0)800 886100 Website

Application

  • Suitable for use in openings in concrete, aerated concrete, masonry and dry wall.
  • For use sealing flammable PE, PE-HD, PVC-U, PVC or PVC-C pipes from 50 mm to 160 mm in diameter in penetrations through fire compartment walls and floors.
  • Range of approved applications publicly present in 3rd party documents: ETA-10/0405.


Description

Intumescent, flexible firestop wrap strip to help create a fire and smoke barrier around combustible pipe penetrations.


Features and benefits:

  • Quicker and easier installation – no hooks, anchors or drilling.
  • Installed inside the base material – ideal when space and access are limited.
  • Different backfilling and sealing materials are covered.
  • Endless solution – one product for most penetrant sizes.


Comes in Two Different Options:

  • CFS-W SG (ready-to-use pre-cut version).
  • CFS-W EL (endless strip solution to be cut to required size).

General information

Color

Red

Black

Material

Intumescent

Shape

Rectangle

Length

169 mm

210 mm

311 mm

370 mm

421 mm

Show more

Width

45 mm

Height

4.5 mm

9.0 mm

13.5 mm

Uniclass

Pr_65_52_61_15 Concealed intumescent pipe collarsPrimary

CAWS

P12/44 Pipe collar - insulated wrap

Specification data - Concealed intumescent pipe collars

Sizes

10 000 x 45 x 4.5 mm.

Guidance for specification option:

Length x width x thickness/ height.

Fire performance

240 hours.

Application temperature

-5 to 50°C.

Temperature resistance

-20 to 80°C.

Reaction to fire class

Class E.

VOC emissions

3.1 g/L.

Bacteria resistance (to EN846)

Class 0.

Third party certifications

European Technical Approval (ETA)

ETA-10/0405 for CFS-W Firestop Wrap for Penetrations

UK Technical Assessment (UKTA)

UKTA22 0042 CFS-W Firestop Wrap
