Coloured Cement Mortar - Masonry Mortar
Verified by manufacturer 17 days ago
Masonry mortar made with lime and cement in a range of colours and textures.
Application
Bricklaying for modern walls.
Description
A decorative cement mortar made according to British Standard designations. It is available in two textures and a wide range of colours including off-white for matching in with brickwork. Pre-made samples are available.
General information
Color | Manufacturer guidanceA range of colours as detailed on the Lime Green website. |
Finish | Manufacturer guidance2 textures: RG (regular grit for joints from around 8mm) and CG (coarse grit for joints of around 12mm) |
Material | Cementitious |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | F10/5 Facing brickwork F10/230 Reclaimed brick facing brickwork F10/295 Manufactured stone blockwork F10/290 Manufactured stone blockwork F10/110 Clay facing brickwork F10/255 Concrete facing blockwork F10/18 Concrete facing blockwork F10/20 Manufactured stone blockwork F10/10 Reclaimed brick facing brickwork |
Specification data - Cement-gauged mortars
Standard | To EN 998-2. |
Mortar type | Batched dry cement:lime:sand. |
Mix | 1:¼:3 (cement:lime:sand) (Mortar Class 12).Guidance for specification option: Class i according to the BS EN 998-2 National Annex. For cappings, copings and sills. 1:½:4½ (cement:lime:sand) (Mortar Class 6).Guidance for specification option: Class ii according to the BS EN 998-2 National Annex. For use below DPC and in chimney stacks. 1:1:6 (cement:lime:sand )(Mortar Class 4).Guidance for specification option: Class iii according to the BS EN 998-2 National Annex. General use. 1:2:9 (cement:lime:sand) (Mortar Class 2).Guidance for specification option: Class iv according to the BS EN 998-2 National Annex. |
Colour | Chalk.Tallow.Grinshill.Purbeck.Honeysuckle.Barley.Bath.Cotswold.Stone.Earth.Salmon.Birch.York.Ochre.Ironstone.Corfton.Bracken.HarnageTugford.Terracotta.Penrhyn.Farringdon.Autumn.Cinders. |
Reaction to fire classification | Class A1. |
Texture | RG texture. Guidance for specification option: Regular grit or joints of around 6 mm and wider. CG texture. Guidance for specification option: Coarse grit for joints of around 10 mm and wider. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | Aggregate recovery from washing |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 10 % |
Literature
Coloured Cement Mortar Datasheet
Case studies
Penfold Place
