Compact Collection - CGS, CGF
Verified by manufacturer 3 months ago
Standard - 3660 x 1560
Standard - 3660 x 1560
Standard and fire retardant compact laminates.
Application
- For indoor horizontal and vertical surfaces.
- Suitable to be used in indoor environments with demanding conditions, such as high wear and tear or humidity levels.
Description
SURFORMA® decorative compacts, according to EN 438, are a robust material for indoor environments with demanding conditions, either horizontal or vertical. They can withstand high impacts, thus ensuring reliability and safety. The surface of the laminate is antibacterial, validated accordingly to Japanese regulation JIS Z 2801.
Features and benefits:
- Versatile.
- Easy to clean and stain-resistant.
- Abrasion and scratch-resistant.
- Durable.
- Available in various colours, patterns and surface textures, providing extensive options for architects and designers.
- Low VOC emissions.
- Meet the most stringent requirements of EN 438 and NEMA LD-3.
- FSC® and PEFC™ certified
General information
Color | Beige Black Blue Brown Cream |
Finish | Matt Other Guidance for specification option: Topface. |
Material | Laminate Guidance for specification option: Compact laminate. |
Shape | Rectangle |
Length | 3050 mm 3660 mm |
Width | 1320 mm 1560 mm |
Height | 3 mm 20 mm Manufacturer guidanceThickness. |
Uniclass | |
CAWS | N10/110 Purpose-made L20/280 Doors K32/10 Panel cubicles K13/160 Proprietary K32/120 Panel cubicles L20/60 Doors L20/45 Doors N10/10 Purpose-made K13/160 Proprietary |
Specification data - Compact or solid grade high-pressure laminate (HPL) boards
Grade | HPL/ BS EN 438-4/ CGS. |
Fire performance | Manufacturer guidanceFire retardant available on request. Consult manufacturer for details and insert requirements. |
Thickness | 3–20 mm.Guidance for specification option: Consult manufacturer and insert requirements. |
Panel size | |
Length | 3660 mm. |
Width | 1560 mm. |
Finish | Soft (LP).Topface (TF). |
Colour | Snow White (B111).Guidance for specification option: LRV: 91.5. Pearl White (B4062).Guidance for specification option: LRV: 87.4. Light Grey (L166).Guidance for specification option: LRV: 54.8. Dark Grey (L167).Guidance for specification option: LRV: 12.2. Black (L3031).Guidance for specification option: LRV: 6.1. Manufacturer guidance
|
Core | Compacts black core. Guidance for specification option: Compact in white core available on request. Consult manufacturer for details and insert requirements. |
Cleaning | To EN 438-2:26, Stain resistance: 5/ 4 rating (minimum). Guidance for specification option: Group 1 e 2 / Group 3. |
Wear resistance | To EN 438-2:10, 150 revolutions. |
Third-party certification | Not required. FSC® and PEFC™ certified. |
