Contemporary hinged Loft Hatch

Verified by manufacturer 5 months ago

PD35

Access Building Products Ltd Variant:

Plastic loft hatch range with three insulation options which meet or exceed Part L building regulations. Hinged, drop down hatch. Meets NHBC guidelines for minimum clear opening. Size 560 x 760mm.

Jump to:
+44 (0)1423 874753 Website

Application

For residential applications. Suitable for ceiling use.

Description

Hinged loft hatch. Designed with a slim and contemporary frame, this hatch features a flat lid and is equipped with compression seals to eliminate draughts between the frame and lid. When closed, the lid securely compresses against the draught seals, ensuring optimal insulation. Made from white injection moulded plastic, this loft hatch requires no decorating or maintenance.


Choose from three insulation options: the PD35 offers 55 mm insulation (U Value 0.35 W/m²K), PD25 provides 100 mm EPS insulation (U Value 0.25 W/m²K) and PD15 provides 150 mm EPS (U Value 0.15 W/m²K).


Size: 560 x 760mm to suit 600mm joist centres. Overall size from outside edge to outside edge of frame 628 x 828mm.


The loft hatch has undergone UKAS accredited air infiltration tests, which confirm compliance without the need for additional sealant to the external frame. Additionally, the loft hatch insulation is CFC and HCFC-free, with an ODP (ozone depletion potential) rating of zero. It also complies with The Code for Sustainable Homes standards, with a GWP (global warming potential) rating of less than 5 (standing at zero).


Fitting information: The loft hatch is designed for easy DIY installation. The frame comes with pre-formed screw holes, simplifying the fitting process.


Compatibility with loft ladders: The loft hatches are compatible with Access Building Products' entire range of loft ladders. Please note that due to the increased insulation depth of the PD15, a minimum distance of 250 mm deep joists or timber plant combination is required for ladder installation. If the distance is less, you may need to raise the ladder fixing point using a timber plant.


Features and benefits:

  • User-friendly design.
  • Meets NHBC compliance standards, ensuring a minimum clear opening of 520 mm in any direction.
  • Maintenance-free and guaranteed not to discolour over time.
  • The hinged lid is positioned on the short side of the frame; to open, twist the catch and lower the lid downwards.
  • Fitted with draught seals, the loft hatch guarantees airtightness, preventing unwanted air leakage and maintaining energy efficiency.

General information

Color

White

Material

Plastic

Shape

Rectangle

Length

828 mm

Guidance for specification option:

Overall length (edge to edge of outer frame)

760 mm

Guidance for specification option:

Nominal length

Width

628 mm

Guidance for specification option:

Overall width (edge to edge of outer frame)

560 mm

Guidance for specification option:

Nominal width for fitting

Height

55 mm

105 mm

120 mm

Warranty description

Two year

Uniclass

Pr_30_59_36_01 Access panelsPrimary

CAWS

L20/60 Doors

L20/630 Hatches

Specification data - Access panels

Position

Ceiling-mounted.

Size

Structural opening: 560 x 760 mm; Clear opening: 670 x 533 mm.

Frame

Exposed picture frame type.

Panel

-

Material

Plastic.

Latch or lock type

Twist lock.

Operation

Swing-down.

Integral accessories

Weatherstrips to frame.

U-value

0.35 W/m²K.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %

BIM objects

Platform Compatible Version
Revit
-

1

Literature

PD Contemporary Loft Hatch

PD Contemporary Loft Hatch

PD Contemporary Loft Hatch Technical Drawing

PD Contemporary Loft Hatch Technical Drawing
