Ecophon Focus™ D/A - Ceiling System

Name: Ecophon Focus™ D/A - Ceiling System
Brand: Saint-Gobain Ecophon
SKU: bqz8byANnKbJhzxN4UEsWg

Verified by manufacturer 2 days ago

Saint-Gobain Ecophon

Product certifications:

Indoor Air Comfort – Eurofins
Certificate type
EPD
Certificate type

An acoustic suspended ceiling system for corridors.

Jump to:

+44 (0)1256 855250 Website

Application

Ceiling applications in corridor solutions where long panels are required, including healthcare, education and offices.

Description

An acoustic suspended ceiling system for corridors, which features an edge D on the long side and edge A on the short side. Each panel is individually demounted. Fulfills the strictest functional and aesthetic demands.

Features and benefits:

Absorption class A.
Painted edges.
Easy to demount.
Easy to clean with a wet wipe.
Cradle to Cradle Certified® Bronze.

General information

Color	White Guidance for specification option: NCS S 0500-N. 85% light reflectance. Gloss <1. Black Grey Orange Blue Pink Green Yellow Red Other Show more
Finish	Painted Other Guidance for specification option: Akutex™ FT.
Material	High-density glass wool
Shape	Rectangle
Length	1720 mm 2000 mm 2400 mm
Width	600 mm
Height	20 mm Guidance for specification option: 20 mm standard tile thickness. 200 mm standard overall depth of system. 50 mm minimum overall depth of system.

Uniclass	Ss_30_25_22_51 Modular suspended ceiling systemsPrimary
CAWS	K40/265 Infill units K40/105 Suspended ceiling system K40/10 Unit/ modular suspended ceilings K40/115 Unit/ modular suspended ceiling system

Specification data - Modular suspended ceiling systems

Classification data
System performance	Acoustic performance
Ceiling support	Connect™ T24 grid.
Support fasteners	Connect™ end fixing plate.
Ceiling units	Ecophon Focus™ D/A - glass wool infill units.
Barriers in ceiling void	-
Fire barriers	- Manufacturer guidance Insert requirements or omit.
Acoustic barriers	- Manufacturer guidance Insert requirements or omit.
Plenum barriers	- Manufacturer guidance Insert requirements or omit.
System accessories	- Manufacturer guidance Insert requirements or omit.
Installation	M17 - Corridor installation.
Indoor climate	Eurofins Indoor Air Comfort® Gold, French VOC A+.
Sound absorption	Class A to BS EN ISO 11654. Guidance for specification option: Noise reduction coefficient: 0.80 αw (Overall depth of system: 60 mm). Noise reduction coefficient: 0.95 αw (Overall depth of system: 200 mm). Manufacturer guidance Noise reduction will change dependent on the overall depth of system - consult manufacturer for details.
Reaction to fire	To EN 13501-1, A2-s1,d0.
Size (length x width)	1720 x 600 mm. 2000 x 600 mm. 2400 x 600 mm.
Thickness	20 mm.
Trim	Connect™ angle trim. Connect™ Shadow-line trim.
Weight	2.9 kg/m².
Standard	CE marked according to the European harmonized standard EN 13964.
Finish	White frost. Guidance for specification option: NCS S 0500-N. 85% light reflectance. Gloss <1. Moonlight sky. Highland fog. Sunset heat. Ocean storm. Morning drizzle. Peach rose. Goji berry. Scallop shells. Fresh clover. Sage garden. Eucalyptus leaf. Summer forest. Golden field. Ruby rock. Wet sand. Silent steam. Dark diamond. Cloudy day. Volcanic ash. Silver stone. Silk slate.

Sustainability data

Material	High-density glass wool
A1–A3 ('Production stage')	Embodied carbon as defined in BS EN 15804
Normalized unit
Declared unit	4.32 kg CO₂ eq/m² Certified Guidance for specification option: A1–C4 figure.
Recyclability	Fully recyclable
Recycled content As defined in clause 7.8 of BS EN ISO 14021	57 %
