Finish Facades Pinnacle - Hook On Rainscreen System
Verified by manufacturer 2 days ago
Hook on cassette aluminium rainscreen system.
Application
Suitable for a wide range of applications, including residential, commercial and industrial.
Description
Pinnacle is an innovative cassette hook on rainscreen system that elevates the aesthetics of cladding with a simple and quick installation process. Pinnacle represents the most deluxe system Finish Facades offers, and has been designed and developed to directly address the aestheticism and performance of rainscreen cladding, including fire performance.
Features and benefits:
- Deluxe system.
- Available in panel sizes up to 1200 x 3800 mm.
- Manufactured to project specific sizes to form a multi-panel build up or full storey height arrangement.
- The integrated slots within the aluminium cladding system allows for fast and easy hook-on mounting and dismounting.
- Panels can be removed in isolation for any maintenance requirements.
- Cladding panels are available in a range of finishes including pre-coating, with the option of a bespoke pre-coat material, powder coating, matt finish, and anodizing.
- CWCT tested and EN 13501-1 certified.
- The Pinnacle hook on rainscreen system is A1 and A2 S1-d0 fire classified.
General information
Color | Other |
Finish | Powder-coated Matt Anodized |
Material | Aluminium |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | H92/120 Rainscreen cladding |
Specification data - Drained and back-ventilated rainscreen cladding systems
Classification data | |
System manufacturer | Finish Facades Ltd. |
Thermal insulation | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Breather membrane | |
Material | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Fasteners | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Secondary support structure | Aluminium carrier rails. |
Cavity fire barriers | |
Horizontal | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Vertical | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Cladding panels | |
Material | Pinnacle aluminium hook on cassette panels. |
Panel joints | Sealed joints. |
Reveals | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
System accessories | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Fire performance | CWCT tested and EN 13501-1 certified. |
Sustainability data
Material | Aluminium |
