Fortex Prison Mesh/ Anti Climb
Verified by manufacturer 1 day ago
1270 mm high
1270 mm high
A security mesh fencing system with narrow apertures.
Application
Suitable for:
- Ministry of Defense (MoD).
- Police stations.
- Secure units.
- Airports.
- Hospitals.
- Schools.
- Utility suppliers.
Description
A security mesh fencing system with narrow apertures that prevent intruders from getting a foot or finger hold, making climbing the structure difficult.
Features and benefits:
- Compliant with BS 1722-14.
- Security fixings included.
- Anti-climb fence.
- High security level.
- Multiple panel heights available.
- Full length lacing strap.
- Suitable for multiple applications.
- Polyester powder-coated to a choice of colours.
- Laser cut and robotically welded using modern folding and bending machines.
General information
Color | Green Black Other Guidance for specification option: Polyester powder-coated to a choice of colours. Contact manufacturer for details. |
Finish | Powder-coated |
Material | Metal |
Shape | Rectangle |
Width | 2515 mm |
Height | 1270 mm 1800 mm 2000 mm 2135 mm 2400 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | Q40/28 Open mesh steel panel security fencing Q40/30 Proprietary fencing Q40/27 Open mesh steel panel general purpose fencing Q40/430 Proprietary fencing Q40/126 Open mesh steel panel security fencing Q40/125 Open mesh steel panel general purpose fencing |
Specification data - Metal mesh panel fencing systems
Standard | To BS 1722-14. |
Category | 3. |
Posts | 60 x 60 mm (SHS). |
Panels | Metal welded mesh panels. |
Site applied finishes | Polyester powder-coated.Guidance for specification option: Polyester powder-coated to a choice of RAL colours. Contact manufacturer for details. |
System accessories | Not required.Plastics post tops.Full length lacing strap.M8 security screw. |
WireDiameter | 4 mm (vertical and horizontal). |
Aperture size | 76.2 x 12.7 mm. |
Post centres | 2440 mm. |
Dimensions | 1270 x 2440 mm. Manufacturer guidanceH x W. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Turkey |
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 0.16 kg CO₂ eq/unit Self declared |
Recyclability | 100 |
