Fortex Prison Mesh/ Anti Climb

Verified by manufacturer 6 months ago

1270 mm high

IAE Variant:

A security mesh fencing system with narrow apertures.

Jump to:
+44 (0)1782 339320 Website

Application

Suitable for:

  • Ministry of Defense (MoD).
  • Police stations.
  • Secure units.
  • Airports.
  • Hospitals.
  • Schools.
  • Utility suppliers.

Description

A security mesh fencing system with narrow apertures that prevent intruders from getting a foot or finger hold, making climbing the structure difficult.


Features and benefits:

  • Compliant with BS 1722-14.
  • Security fixings included.
  • Anti-climb fence.
  • High security level.
  • Multiple panel heights available.
  • Full length lacing strap.
  • Suitable for multiple applications.
  • Polyester powder-coated to a choice of colours.
  • Laser cut and robotically welded using modern folding and bending machines.

General information

Color

Green

Black

Other

Guidance for specification option:

Polyester powder-coated to a choice of colours. Contact manufacturer for details.

Finish

Powder-coated

Material

Metal

Shape

Rectangle

Width

2515 mm

Height

1270 mm

1800 mm

2000 mm

2135 mm

2400 mm

Show more

Warranty description

Ten year

Uniclass

Ss_25_14_61_51 Metal mesh panel fencing systemsPrimary

CAWS

Q40/28 Open mesh steel panel security fencing

Q40/30 Proprietary fencing

Q40/27 Open mesh steel panel general purpose fencing

Q40/430 Proprietary fencing

Q40/126 Open mesh steel panel security fencing

Q40/125 Open mesh steel panel general purpose fencing

Specification data - Metal mesh panel fencing systems

Standard

To BS 1722-14.

Category

3.

Posts

60 x 60 mm (SHS).

Panels

Metal welded mesh panels.

Site applied finishes

Polyester powder-coated.

Guidance for specification option:

Polyester powder-coated to a choice of RAL colours. Contact manufacturer for details.

System accessories

Not required.

Plastics post tops.

Full length lacing strap.

M8 security screw.

WireDiameter

4 mm (vertical and horizontal).

Aperture size

76.2 x 12.7 mm.

Post centres

2440 mm.

Dimensions

1270 x 2440 mm.

Manufacturer guidance

H x W.

Sustainability data

Contains Red List materials

No

Country of material origin

Turkey

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0.16 kg CO₂ eq/unit

Self declared

Recyclability

100
