Hook-On Ceilings

Verified by manufacturer 6 months ago

LMD-E 200 Hook-on ceiling

Lindner Group Variant:

A range of metal ceilings with ceiling panels supported by a fully concealed hook-on suspension system.

Jump to:
BOS
020 8246 6333 Website

Application

  • Recreation and culture.
  • Workplace.
  • Healthcare.
  • Education.
  • Transport.
  • Industry.
  • Public institutions.
  • Hotels and gastronomy.
  • Public areas.

Description

A range of ceilings with customizable metal ceiling panels supported by a fully concealed hook-on suspension system. Manufactured in accordance with European standards and the technical regulation of TAIM e.V.


Features and benefits:

  • Hygienic and easy to clean.
  • Easy to maintain.
  • Homogeneous ceiling surface due to concealed substructure (hook-on ceilings).
  • Freely spanned construction (hook-on corridor ceilings).
  • The products have a specific EPD according to the valid standards (EN 15804/ ISO 14025).

General information

Color

White

Finish

Powder-coated

Guidance for specification option:

Electrostatically applied.

Material

Steel

Uniclass

Ss_30_25_22_51 Modular suspended ceiling systemsPrimary

CAWS

K40/10 Unit/ modular suspended ceilings

K40/115 Unit/ modular suspended ceiling system

Product range

Ceilings

Specification data - Modular suspended ceiling systems

System performance

Fire performance to BS EN 13501, A2-s1, d0.

Ceiling support

Metal suspended ceiling hangers.

Ceiling units

Metal infill units.

System accessories

None.

LMD-RK 10 – Inspection hatch.

Standard

To EN 13964.

Third-party certification

TAIM e.V.

Acoustic infills

Not required.

Acustica – Acoustic fabric inlay.

Insula – Mineral wool inlay in acoustic foil.

Colour

RAL 9010.

Guidance for specification option:

Manufacturer's standard.

RAL.

Guidance for specification option:

Insert requirements.

NCS.

Guidance for specification option:

Insert requirements.

Luminaires

IS 17 – Integrated luminaire for general areas.

IS 22 – Integrated luminaire for monitor work stations.

IS 450 – Integrated luminaire for office and general areas.

LK 73 – Light channel.

QZI – Integrated luminaire with cell louvres.

Show more

Perforation

BASICline.

REGULARline.

SPREADline.

Manufacturer guidance

Consult manufacturer for perforation patterns.

Sound absorption

-

Manufacturer guidance

Dependent on level of perforation and acoustic inlay. Consult manufacturer.

Type

LMD-E 200 Type 2, Hook-on/ Lay-on.

LMD-E 200 Type 3, Hook-on/ Lay-on, self-aligning.

LMD-E 200 Type 4, Hook-on on both sides.

LMD-E 200 Type 5, Hook-on/ Lay-on, cassette.

Ventilation

Not required.

AirBeam – Heated/Chilled beams.

AirBox E – Exhaust air elements.

AirBox S – Supply air elements.

Wall connection

Open.

L-angle.

Shadow gap trim.

Powder coating

COLOURline.

MOODline.

ARTline.

GRAPHICline.

Coatings

Meteo.

Mutex.

Fire resistance

To NBN 713.020, 45 minutes.

Durability

To DIN EN 13964, exposure class A.

Joint width

Hairline joint.

1 mm.

3 mm.

5 mm.

Panel size

-

Manufacturer guidance

Length up to 3000 mm, width up to 1250 mm, height up to 50 mm, insert requirements.

Sustainability data

Contains Red List materials

No

Country of product manufacture

Germany

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
