Hydropave Fusion Duo | Permeable Block Paving

Name: Hydropave Fusion Duo | Permeable Block Paving
Brand: Tobermore
SKU: j6JUwk5M1L5SmnByAAaXBH

Verified by manufacturer 5 months ago

Tobermore

Third party certifications:

EPD
Certificate type

Permeable paving that emulates traditional natural granite.

Jump to:

BOS

+44 (0)844 800 5736 Website

Application

For residential and commercial applications when used in conjunction with the correct sub-base design, and in accordance with the latest British standard.

Description

Designed specifically to provide a random bond finish, the product's aesthetic qualities can match period design or add character to modern buildings.

Features and benefits:

The course texture surface exposes the sparkling black and white granite aggregates to provide a distinctive silver appearance similar to natural granite.
Has frost protection.
BREEAM rating A (A+ can be achieved when used with recycled sub-base).

General information

Color	Grey Guidance for specification option: Graphite Silver Guidance for specification option: Silver Yellow Guidance for specification option: Sandstone
Finish	- Manufacturer guidance Granite Aggregate
Material	Concrete
Shape	Square Rectangle
Length	208 mm 173 mm
Width	173 mm
Height	60 mm

Uniclass	Pr_25_93_60_17 Concrete paving blocksPrimary
CAWS	Q24/115 Permeable concrete block paving – total infiltration Q24/117 Permeable concrete block paving – partial infiltration Q24/119 Permeable concrete block paving – no infiltration

Product range	Tobermore Hydropave I Permeable Paving

Specification data - Concrete paving blocks

Standard	To BS EN 1338. Manufacturer guidance Installed to BS 7533-3.
Physical properties	-
Colour	Graphite. Sandstone. Silver.
Finish	Granite aggregate.
Profile	-
Paver type	Regular plan form.
Arrises	Chamfer.
Dimensions and associated tolerances	-
Nominal sizes	208 x 173 x 60 mm. 173 x 173 x 60 mm.
Tolerances on diagonals	To BS EN 1338.
Weathering resistance	Class 3. Guidance for specification option: ≤1.0 kg/m² as a mean with no individual value >1.5 kg/m².
Abrasion resistance	Class 3.
Slip resistance	Mean unpolished skid resistance value (USRV): >45.
Recycled content (minimum)	Not less than 6%.

Efflorescence	Minimum 12 hour vapour curing to significantly reduce the possibility of efflorescence.
Drainage void width	5% to accommodate correct grit grading, reduced maintenance and maximise drainage flow rate.
Permeability	29 000 L/s/ha
Strength	>3.6 MPa.
EnergyUsed	100%.
WaterUsed	100%.
BREEAM rating	A (A+ can be achieved when used with recycled sub-base).
Surface finish	Hard-wearing surface layer with a minimum layer of 4 mm and >350 kg/m³ cement.

Sustainability data

Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Concrete
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	18.33 kg CO₂ eq/m² Certified Lower emissions Manufacturer guidance 24-26
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	- Manufacturer guidance Not less than 6%.
