Hydropave Pedesta | Permeable Block Paving

Verified by manufacturer 2 months ago

Tobermore Third party certifications:
  • EPD

    EPD

    Certificate type

Permeable paving block.

Jump to:
BOS
+44 (0)844 800 5736 Website

Application

For residential and commercial applications when used in conjunction with the correct sub-base design, and in accordance with the latest British standard.

Description

Permeable version of Pedesta paving blocks, with a simple rectangular profile that allows the creation of distinctive laying patterns.


Features and benefits:

  • Has frost protection.

General information

Color

Other

Guidance for specification option:

  • Bracken.
  • Brindle.
  • Charcoal.
  • Natural.

Finish

Smooth

Material

Concrete

Shape

Rectangle

Length

200 mm

Width

100 mm

Height

60 mm

80 mm

Uniclass

Pr_25_93_60_17 Concrete paving blocksPrimary

CAWS

Q24/115 Permeable concrete block paving – total infiltration

Q24/117 Permeable concrete block paving – partial infiltration

Q24/119 Permeable concrete block paving – no infiltration

Product range

Tobermore Hydropave I Permeable Paving

Specification data - Concrete paving blocks

Standard

To BS EN 1338.

Manufacturer guidance

Installed to BS 7533-3.


Physical properties

-

Colour

Bracken.

Brindle.

Charcoal.

Natural.

Finish

Smooth.

Dimensions and associated tolerances

-

Nominal sizes

200 x 100 x 60 mm.

200 x 100 x 80 mm.

Slip resistance

Extremely low (>75 USRV).

Skid resistance

Extremely low (>75 USRV).

Efflorescence

Minimum 12 hour vapour curing to significantly reduce the possibility of efflorescence.

Drainage void width

5.5% to accommodate correct grit grading, reduced maintenance and maximise drainage flow rate.

Permeability

32 000 L/s/ha.

Strength

>3.6 MPa.

EnergyUsed

100%.

WaterUsed

100%.

BREEAM rating

60 mm: A; 80 mm: B to the Green Guide to Specification, 4th Edition 2009 (Enhanced rating can be achieved by using a recycled sub-base).

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Concrete

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

-

Manufacturer guidance

  • 60mm 14.17kgCo2 e/m2
  • 80mm 20.98kgCo2 e/m2

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

-

Manufacturer guidance

Not less than 12%

Third party certifications

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Third party certifications

EPD

EPD

Environmental Product Declaration (EPD) Artro 80mm, Hydropave Pedesta 60mm, Hydropave Pedesta 80mm, Hydropave Shannon 60mm, Marker Block 80mm, Pedesta 50mm, Pedesta 60mm, Pedesta 80mm, Shannon 50mm, Shannon 60mm, Toberloc 80mm
