IAE Banbury XL Cycle Shelter

Verified by manufacturer 22 days ago

Banbury XL Cycle Shelter - 20 cycle

IAE Variant:
Third party certifications:
  • ISO 9001 Quality Management

    Certificate type

Premium stylish steel framed cycle shelter. Ideal for a wide range of applications and environments.

Jump to:
BOS
+44 (0)1782 339320 Website

Application

Suitable for providing a sheltered area for bicycles and motor scooters in a range of environments.


Perfect for hotels, schools, universities, workplaces, commercial sites, public transport stations and anywhere a stylish sheltered bike storage solution is needed.

Description

The IAE Banbury cycle shelter provides a stylish and aesthetically pleasing cycle storage solution for a wide range of environments.


Perfect for schools, universities, workplaces, commercial sites, public transport stations and anywhere a stylish sheltered bike storage solution is needed.


The Banbury cycle shelter is fitted with UV resistant roof panels as standard, that resist discolouring due to sun exposure, and the galvanised tubular steel frame will resist rust and corrosion. This allows our shelters to last for a long time, even in the worst of conditions.


The inline modular design allows flexibility in choosing the size of the cycle storage capacity. Sold in 4 meter sections.


Features and benefits:

  • Asthetic solution for outdoor cycle storage.
  • 2 x Toast style 10 cycle racks supplied as standard.
  • Robust tubular steel structure, assembled with anti tamper bolts.
  • 5mm UV resistant PETG roof panels.
  • Welded end frame.
  • Stainless steel fixings to all structural joints.
  • Hot dip galvanized to BS EN ISO 1461.


Options:

  • Powder-coating available in a wide range of colours.
  • Inline extensions available in 4100mm sections.
  • IAE Banbury single is available, with a single cycle rack and smaller footprint.

General information

Color

Finish

Powder-coated

Galvanized

Material

Steel

Polyethylene

Shape

Rectangle

Length

4100 mm

8400 mm

Width

2700 mm

Height

2200 mm

Warranty description

Two year

Uniclass

Pr_20_65_78_58 Open-sided sheltersPrimary
Pr_20_65_78_77 Semi-closed shelters

CAWS

B91/385 Shelter

B91/330 Canopy

B91/340 Cycle shelter

Specification data - Open-sided shelters

Shelter description

Rectangular, with curved roof.

Dimensions

-

Plan size

4300 x 3882 mm.

Height

2479 mm.

Frame

-

Material

Structural steel.

Guidance for specification option:

Tubular frame.

Finish

Galvanized.

Guidance for specification option:

As standard.

Galvanized and powder-coated

Guidance for specification option:

Optional.

Colour

RAL 1021.

RAL 5015.

RAL 6005.

RAL 7016.

RAL 9005.

Roof covering

Polyethylene terephthalate glycol (PETG).

Accessories

None.

Inline extension - 2 m.

Inline extension - 4 m.

Inline extension - 5 m.

Cycles

20 (senior racks, root baseplate fixing).

20 (senior racks, toast rack fixing).

Sustainability data

Contains Red List materials

No

Country of material origin

Turkey

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0.16 kg CO₂ eq/kg

Self declared

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

95 %

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC
-

1

Revit
-

1

Third party certifications

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001:2015 Certificate

Literature

IAE Banbury XL Canopy - Assembly and Maintenance Manual

IAE Banbury XL Canopy - Assembly and Maintenance Manual

Banbury XL Cycle Shelter Specification Sheet

Banbury XL Cycle Shelter Specification Sheet
