IdroStop PVC BI/BE

Verified by manufacturer 9 months ago

IDROSTOP PVC BI20

Mapei (UK) Ltd Variant:

PVC waterstop for sealing structural joints.

Jump to:
+44 (0)121 508 6970 Website

Application

  • Waterstops are used to make water-tight structural joints in underground reinforced concrete constructions to avoid ingress from the water table and in reinforced concrete structures used to contain water, such as swimming pools, water tanks and dams.
  • Used within concrete structures exposed to temperatures from -30 to + 70°C.

Description

A highly flexible waterstop made from high-quality thermo-plastic vinyl resins, which form a product with good resistance to mechanical stresses, the aggressive action of chemical products in alkaline environments, sea-water and acids.

Features and benefits:

  • Highly resistant to perishing caused by sunlight, ozone and other aggressive agents present in the atmosphere and water table.

The dimensions and type of Idrostop PVC used for each application generally depends on the following parameters:

  • Type of structure (for both types of Idrostop PVC).
  • Amount and type of movement predicted (no movement, axial movement, a combination of axial and transversal movements etc).
  • Thickness of the cast concrete (only valid for Idrostop PVC BI).

General information

Material

PVC

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Pr_35_90_15_16 Centrally placed unplasticized polyvinyl chloride (PVC-U) flexible waterstopsPrimary

CAWS

E40/320 Hydrophilic waterstops

Specification data - Centrally placed unplasticized polyvinyl chloride (PVC-U) flexible waterstops

Width

200 mm.

TensileStrength

14 N/ mm².
