K Mix GP Mortar
A range of block, brick and paving mortars.
Suitable for block and brick laying, scratch coats and in paving applications.
K Mix is a range of dry bagged construction mortars which can be used for block and brick laying, scratch coats and in paving applications.
The range includes:
Color | Grey |
Material | Cement based render |
Warranty description | 30 year Guidance for specification option: 30 years if completed to manufacturers specification and guidelines. |
Uniclass | |
CAWS | F10/290 Manufactured stone blockwork F10/355 Concrete common blockwork F10/230 Reclaimed brick facing brickwork F10/315 Clay common brickwork F10/345 Concrete common brickwork F10/360 Autoclaved aerated concrete (AAC) common blockwork F10/110 Clay facing brickwork F10/215 Concrete facing brickwork F10/295 Manufactured stone blockwork F10/255 Concrete facing blockwork F10/385 Engineering brickwork F10/395 Damp-proof course brickwork F10/5 Facing brickwork F10/10 Reclaimed brick facing brickwork F10/36 Concrete common blockwork F10/37 Autoclaved aerated concrete (AAC) common blockwork F10/33 Clay common brickwork F10/18 Concrete facing blockwork F10/20 Manufactured stone blockwork F10/25 Manufactured stone blockwork F10/45 Engineering brickwork |
Colour | Natural Belfast Brown Armagh Grey Tyrone Pine Down Red Manufacturer guidanceSpecial colours can be manufactured on request. |
Coverage | 1.8 kg/ mm thick/ m². |
Temperature | 5–35°C. The product must not be used in frozen conditions. |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
Platform | Compatible | Version |
---|---|---|
- | 1 | |
Revit 2017 | 1 |
