Lime Mortar 0.2 - For Thin Joint Work
Limelite Heritage Lime Mortars are used for most building works or the majority of masonry types in cavity wall construction.
A cement-free blend of natural hydraulic lime and selected aggregates. The mortar is highly workable and combines long term flexibility and breathability with durability. The mortar is available in two aggregate grades, 4 mm grit for standard wider 10mm joints and 2 mm grit for thin joint work, in a range of six colours. Both mortars are available in two strength types M2.5 and M5.0 - also known as HLM2.5 & HLM5.0.
The near zero expansion of NHL binders and the elasticity of pure NHL mortars are such that joint free construction is possible.
Features and benefits:
Color | Brown Guidance for specification option: Light brown. Grey Guidance for specification option: Light and dark grey. Beige Guidance for specification option: Natural, London and Sandstone colours. Other Guidance for specification option: Bespoke colour matching service available. Cream |
Finish | Brushed |
Material | Lime Sand |
Shape | Formless Guidance for specification option: Dry powder. |
Size | Manufacturer guidanceAvailable in 25 kg bags or in bulk. |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | C41/530 Proprietary mortar repairs H51/585 Cement:lime:sand mortar jointing H51/585 Cement:lime:sand mortar jointing Z21/310 Lime:sand mortar mixes M20/330 Proprietary lime:sand M20/310 Lime:sand Z21/310 Lime:sand mortar mixes C41/530 Proprietary mortar repairs M20/57 Lime:sand |
Mortar type | A premixed dry batch of hydraulic lime:sand mix. |
Mix | HLM5.0 - Lime:sand - 1:2.HLM2.5 - Lime:sand - 1:2.25. |
Colour | Natural.London.Sandstone.Light Brown.Light Grey.Dark Grey.Bespoke colour matching.Guidance for specification option: Contact manufacturer and insert requirements. |
Typical yield | Laying: 25 bricks, Re-pointing: 2.8 m² (approximate per 25 kg bag). Guidance for specification option:
|
Certification | Limelite Heritage Lime Mortar is factory blended, tested and packaged to quality control procedures in accordance with BS EN ISO 9001. |
Shelf life | 6 months (subject to temperature and humidity). Guidance for specification option:
|
Minimum storage temperature | Minimum: 5°C, Maximum: 30°C. Guidance for specification option:
|
MaxAggregateSize | 2 mm. |
Typical compressive strength | HLM5.0 is 5.0 N/mm² (at 91 days), HLM2.5 is 2.5 N/mm² (at 91 days). Manufacturer guidanceTechnical performance is derived by laboratory testing at 20°C. |
Freeze/ Thaw Resistance | High. Manufacturer guidanceTechnical performance is derived by laboratory testing at 20°C. |
Chemical resistance | Resistance to sulfates: High. Manufacturer guidanceTechnical performance is derived by laboratory testing at 20°C. |
Durability | Mortar Durability Class: 5–6. Manufacturer guidanceTechnical performance is derived by laboratory testing at 20°C. |
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | Manufacturer guidance20% less CO2 is generated in production than cement and CO2 is actively re-absorbed in carbonation/curing. |
Recyclability | Manufacturer guidanceSupplied in 30% recycled plastic bags that can be recycled upon use |
